STEP 9

Rackmounting Your PowerCenter

A) Remove your PowerCenter trim covers using a 3/32 Allen key (not included). Turn each Allen screw

counter-clockwise until the screw is completely removed.

B) Align one rack ear over the two 3/32 holes on the left side of the PowerCenter, lining up the rack’s

corresponding holes. Using a 3/32 Allen key, turn the two Allen screws (provided) clockwise until tight.

C) Align the remaining two holes on the left side of the PowerCenter with the two holes on the left side

of your rack. Using a Phillips screwdriver, turn the two Phillips screws (provided) clockwise until tight.

D) Repeat Steps B and C for installation of the rack ear on the right side of PowerCenter.

MONSTER

PO

W

ER

MONSTER

PO

W

ER

MONSTER

PO

W

ER

MONSTER

PO

W

ER

HTS 3600 Rack ”Ear”
