INSTALLATION INSTRUCTIONS
• STEP #5
o Install waste system according to manufacturer’s installation instructions.
o NOTE: WASTE SYSTEM SHOWN, DECOLAV
® 9100 DECORATIVE BOTTLE TRAP, IS A
RECOMMENDED ACCESSORY AND NOT INCLUDED!
o Refer to Figure #5.
• STEP #5
o Install faucet and water supply according to manufacturer’s installation instructions.
o NOTE: FAUCET AND WATER SUPPLY NOT INCLUDED!
o Check for leakage.
o Refer to Figure #6 for fi nished vanity.
Bottle trap nut
Bottle trap washer
Bottle trap fl ange
Bottle trap horizontal leg
Bottle trap nut
Bottle trap washer Figure #5
Figure #6
