INSTALLATION INSTRUCTIONS
• STEP #4
o Install vessel, drain and mounting ring according to manufacturer installation instructions.
o Refer to Figure #4.
NOTES:
o VESSEL SHOWN, DECOLAV
® 1000-T ROUND TEMPERED GLASS VESSEL, IS A RECOMMENDED
ACCESSORY AND NOT INCLUDED!
o DRAIN SHOWN, DECOLAV ® 9298 PUSH BUTTON CLOSING UMBRELLA DRAIN, IS A
RECOMMENDED ACCESSORY AND NOT INCLUDED!
o MOUNTING RING SHOWN, DECOLAV ® 9020 MOUNTING RING IS A RECOMMENDED
ACCESSORY AND NOT INCLUDED!
o DO NOT OVERTIGHTEN DRAIN!
Drain
Drain thin washer
Vessel
Mounting ring washer
Mounting ring
Drain thick washer
Drain hard washer
Drain nut
Figure #4
