Specifications
20 QTERM-A12 Terminal
PHYSICAL
S TANDARD V ERSION ( WITH FACTORY - INSTALLED BEZEL )
Dimensions 344.4 (W) x 267.0 (H) x 69.1 (D) mm
Mass 2.05 kg
M ODULAR V ERSION ( WITHOUT FACTORY - INSTALLED BEZEL )
Dimensions 298.9 (W) x 252.6 (H) x 62.8 (D) mm
Mass 1.72 kg
ENVIRONMENTAL
Sealing
UL50 Type 4X Outdoor (pending), NEMA-4X, IP66 (front panel
only)
Temperature
Operating: -30 to 70
°
C
Storage: -30 to 85 °C
Humidity 5 to 95%, non-condensing
Vibration 10 to 1500 Hz, 4 g RMS
Shock 40 g, 11 ms, common orthogonal axes
Electrical transient and
noise
As specified in EN55024
ESD
8 kV contact
15 kV air on all surfaces
POWER
Input voltage range 10 to 32 VDC
Typical power
consumption
8.5 W (~700 mA @ 12 VDC)
OPTIONAL POWER-OVER-ETHERNET (PoE)
Input voltage range 37 to 57 VDC
Typical power
consumption
10.5 W
CPU
ARM Architecture V5TE Marvell PXA300 with Intel XScale technology
Speed 624 MHz
Cache 32 kbytes instruction cache, 32 kbytes data cache
