PSA2S Parts List 1/16/2013

YS #

Description

Qty.

YS #

Description

Qty.

YS #

Description

Qty.

YS #

Description

Qty.

6405 RED 3MM LED 2V0 20MA BRT

1

712 32 X 30 X 72 2 MIL PLASTIC BAG

1

4585 1/4W 1K2 5%MINI T&R RES

2

3500 SHOULDER WASHER SWS605

4

6400 YEL 3MM LED 1V9 6MA HIGHEFF

1

3961 SNAP ON 1.16" INSULATING BUSHING

2

2051 1/4W 1K5 FUSIBLE T&R RES

6

8818 3/4 OD X 3/8 ID X .080 THICK WASHER

1

6408 GRN 3MM LED 1V9 5MA FROSTED

1

4080 _2.0UH COIL 16AWG ZOBEL AIR CORE

2

4935 1/4W 1K5 5% .2"U T&R RES

1

8820 #8 FLAT WASHER JS500

4

6772 BRIDGE 25A 400V WIRE LEAD SIP

1

3899 __18UH MINI INDUCTOR HI-Q T&R

6

4988 1/4W 1K5 5%MINI T&R RES

2

3522 DPDT MINI PC VERT SNP ALT

1

6425 BAV21 200V 0A25 DIODE T&R

2

6497 _304UH CHOKE 95T18AWG/77111MAGNTKS

2

5005 2.0W 1K8 5% T&R RES

1

3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65

1

6825 1N4148 75V 0A45 DIODE T&R

21

6500 2700UH COIL COMMON MODE 7AMP

2

6148 1/4W 2K05 1%MINI MF T&R RES

2

3887 ADHESIVE LINED GROMMET EDGING

2

6892 UF4004 200V 1A0 DIODE ULTRAFAS

6

8529 RUBBER FOOT 65 X 20MM

4

4714 1/4W 2K21 1% T&R RES

2

3394 THERMO/BRKR:N/CLOSED OPEN@74C

1

6438 1N4007 1000V 1A0 DIODE T&R

11

8545 RECESSED RUBBER BUMPER WITH WASHER

4

4864 1/4W 2K7 5% T&R RES

3

3074 POWER CORD 3M V-LOCK (N.A)

1

6733 BAT85 30V 0A2 DIODE SCHT T&R

5

9970 RIGID CASTER

2

4936 1/4W 2K7 5% .2"U T&R RES

1

CH1405U XFMR:LS2100P/PSA2S

1

6432 1N5248B 18V0 0W5 ZENER 5% T&R

8

3485 CLIP 250X032 18-22AWG RIGHT ANGL

2

4805 1/4W 2K87 1% T&R RES

1

6440 1N750ARL 4V7 0W5 ZENER 5% T&R

1

3489 CLIP 250X032 18-22AWG DISCO/INSL

3

6136 1/4W 3K3 5%MINI T&R RES

3

6450 1N5242B 12V0 0W5 ZENER 5% T&R

1

3490 CLIP 250X032 14-16AWG DISCO/INSL

6

4814 1/4W 3K6 5% T&R RES

2

6475 1N5262B 51V0 0W5 ZENER 5% T&R

1

3601 RING TERMINAL 16AWG WIRE & #8 SCREW

1

5028 1/4W 3K74 1% T&R RES

1

6486 1N5244B 14V0 0W5 ZENER 5% T&R

1

4063 1/4IN ISO JCK PCMT VT STER RT SWT

2

4774 1/4W 4K12 1% T&R RES

1

2308 1N4753A-T 36V0 1W0 ZENER 5% T&R

2

4010 XLR FEML PCB MT VERT 24MM AA-SERIES

1

4827 1/4W 4K7 5% T&R RES

5

6728 MC78L05ACP TO92 P 5V0 REG TR V4

1

4100 XLR MALE PCB MT VERT

1

4982 1/4W 4K7 5%MINI T&R RES

5

6856 NJM7815FA TO220 P 15V0 REG IS V1

3

3049 PATCH 04 18AWG 15.0 156

2

4639 1/4W 4K99 1% T&R RES

2

6857 NJM7915FA TO220 N 15V0 REG IS V2

1

2328 8 CIR XH-HEADER 0.098IN

2

4939 1/4W 5K1 5% .2"U T&R RES

1

5101 BC550C TO92 NPN TRAN T&R TB

1

3042 PATCH 08 22AWG 13.0 XH FLAT

1

4862 1/4W 5K6 5% T&R RES

1

5103 MPSA06 TO92 NPN TRAN T&R TA

1

2899 CORE:FERRITE

2

4828 1/4W 6K8 5% T&R RES

1

5107 2N5551 TO92 NPN TRAN T&R TA

2

3818 EMI SUPPRESSION FERRITE BEAD T&R

2

4787 1/4W 7K960 0.1% *** T&R RES

2

5108 2N5401 TO92 PNP TRAN T&R TA

5

3962 EMI FILTER FOR ROUND CABLE

1

4762 1/4W 9K760 0.1% *** T&R RES

2

5105 MPSA13 TO92 NPN DARL T&R TA

3

3414 INTERNATIONAL PC MOUNT FUSEHOLDER

4

5016 1.0W 9K760 0.5% *** T&R RES

2

2307 IRGP35B60PDPBF T0247 NPN IGBT TM

4

2438 12.0 AMP SLO-BLO .25X1.25 FUSE

2

4940 1/4W 10K 5% .2"U T&R RES

2

2318 LM6172IN 8PIN DIP FAST DUAL OPAMP

1

8551 BAR HANDLE RIGHT ANGLE TOP LOAD

1

4983 1/4W 10K 5%MINI T&R RES

9

6542 LM318 IC OP AMP

1

8565 BAR HANDLE ALL METAL RECTANGULAR

3

6116 1/4W 10K0 1%MINI MF T&R RES

8

6840 MC33078P IC DUAL OP AMP

3

9170 STAND ADAPTER CAST

1

4768 5.0W 12K 5% BLK RES

2

6882 TL072CP IC FET DUAL OP AMP

9

9877 METAL GRILL CLOTH BACKING 54" WIDE

3.9

4856 1/4W 12K 5% T&R RES

1

6884 NE5532N IC DUAL OP AMP

1

3692 HEATSINK TO-220 W/O TAB BLK ANODIZE

2

4775 1/4W 14K0 1% T&R RES

1

6640 LM311 IC VOLTAGE COMPARATOR

2

3501 B52200F006 COMP WASH #4 SMALL

5

4979 1/4W 15K 5%MINI T&R RES

3

6745 LM13600N IC XCONDUCTANCE AMP

2

3745 DUAL XSISTOR PBL SPRING CLEAR ZINC

2

4784 1/4W 17K40 0.1% *** T&R RES

2

6586 IRS21844PBF IC HILO FET DRIVER

2

3798 8" NYLON CABLE TIE

1

5021 1/4W 18K7 1% T&R RES

1

6603 74HC14N IC HEX INV SCHMID

2

3803 NYLON SECUR-A-TACH MINI PLASTIC TIE

1

4832 1/4W 22K 5% T&R RES

7

2306 FOD816 4PINDIP ACINPUT OPTOCOUPLER

1

3810 4" NYLON CABLE TIE

11

4833 1/4W 27K 5% T&R RES

2

6489 __5R 20% THERM-SURGR NTC KNK LEADS

1

3841 5.5" NYLON CABLE TIE

6

6129 1/4W 27K 5%MINI T&R RES

1

6543 48R 265V RESETTABLE THERMISTOR PTC

1

3852 STICK ON CABLE WRAP ANCHOR

2

6122 1/4W 33K 5%MINI T&R RES

2

5200 _10P 200V 5%CAP T&R RAD CER.2NPO

1

3558 TERM HOUSING 4 CIR .156/RAMP

1

6119 1/4W 47K 5%MINI T&R RES

10

5817 _15P 100V 2%CAP T&R RAD CER.2NPO

1

3559 TERM HOUSING 8 CIR .156/RAMP

2

4836 1/4W 68K 5% T&R RES

1

5203 _47P 100V 2%CAP T&R RAD CER.2NPO

2

3575 CONN PLUG 3 POS. .084" V-2 FEMALE

1

4942 1/4W 100K 5% .2"U T&R RES

2

5199 100P 100V 2%CAP T&R RAD CER.2NPO

2

3538 24 PIN BREAKAWAY LOCK .156

1.667

6120 1/4W 100K 5%MINI T&R RES

4

5196 150P 100V 2%CAP T&R RAD CER.2NPO

2

4146 3 PIN POWER PIN HEADER MALE POLZED

1

2314 1/2W 150K 0.5% MF T&R RES

2

5197 220P 100V 2%CAP T&R RAD CER.2NPO

2

4147 6 PIN POWER PIN HEADER MALE POLZED

2

4949 1/4W 180K 5% .2"U T&R RES

2

5201 470P 100V 5%CAP T&R RAD CER.2NPO

1

4145 9PIN 3X3 POWER PIN HEADER

1

4841 1/4W 220K 5% T&R RES

3

5820 470P 200V 5%CAP T&R BEAD NPO

2

3549 TRIFURCON TERM .156

20

6135 1/4W 270K 5%MINI T&R RES

1

5206 __1N 400V 5%CAP T&R RAD .2FLM

1

3576 SOCKET TERMINAL 14-20 AWG TAPE/REEL

2

4842 1/4W 330K 5% T&R RES

1

5213 __1N 630V 5%CAP T&R RAD PRO. 2FM

5

8637 ROUND PUSH BUTTON 1/4" BLK 24MM

1

6127 1/4W 470K 5%MINI T&R RES

2

5422 __1N 50V 10%CAP T&R BEAD NPO

1

8653 LOW PROFILE POINTER AT 12 KNOB

3

4844 1/4W 1M 5% T&R RES

6

5606 __1N5 50V 10%CAP T&R RAD CER.2X7R

3

6497CORE 77111-A7 KOOL MU POWDER CORES

2

4948 1/4W 1M 5% .2"U T&R RES

4

6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC

7

3817 _1.5MH COIL INPUT COM MODE

1

4845 1/4W 2M2 5% T&R RES

1

5204 _10N 100V 10%CAP T&R RAD .2FLM

3

8206 YORKVILLE LOGO METALPHOTO

1

4809 1/4W 10M 5% T&R RES

1

5834 _10N 400V 10%CAP BLK RAD POLY FLM

2

8701 4-40 KEPS NUT ZINC

3

4751 1/4W 22M 5% T&R RES

1

5205 _15N 100V 10%CAP T&R RAD .2FLM

1

8793 4-40 HEX NUT ZINC

2

3722 RELAY 1A 30AMP DC24 036MA PC-C

1

6435 _22N 275V 20%CAP BLK 'X2' 15MM AC

1

2331 6-32 X 3/8" PEM THRD SPACER 0.213

7

9975 #4 X 1/2 PAN PHIL TYPE A B.O.& WAX

6

5226 _68N 100V 5%CAP T&R RAD .2FLM

1

8800 6-32 KEPS NUT ZINC

10

8811 #6 X 1 1/4 FLAT HD SQ SCKT WS ZN CL

42

5310 _68N 50V 10%CAP T&R BEAD X7R

1

9931 6-32 NYLON INSERT LOCK NUT

4

9401SS #10 X 3/4 SS PAN PH TYPE A BO&W

54

5212 100N 63V 5%CAP T&R RAD .2FLM

40

8787 8-32 KEPS NUT ZINC

2

8865 4-40 X 5/16 PAN PH MS JS500

6

5216 100N 200V 5%CAP T&R RAD .2CER

11

8604 10-32 T NUT

16

8741 4-40 X 1/2 PAN PH MS JS500

4

5242 100N 250V 20%CAP BLK 'X2' 15MM AC

2

8602 1/4-20 T NUT

22

8871 4-40 X 5/8 PAN PH MS JS500

1

5314 100N 50V 10%CAP T&R BEAD X7R

1

8898 1/4-20 CAGE NUT C79 98142027

8

8832 6-32 X 1/4 PAN PH TAPTITE JS500

10

5231 220N 63V 5%CAP T&R RAD .2FLM

3

8797 5/16-18 KEPS NUT JS500

1

8801 6-32 X 3/8 PAN PH TAPTITE JS500

14

5318 220N 50V 10%CAP T&R BEAD X7R

2

4124 SILPAD 1500ST 1.100 X0.820 BERQUIST

4

8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA

10

5233 330N 63V 5%CAP T&R RAD .2FLM

1

4133 SARCON 30GTR THERMOPAD 1"X8.31"

1

8835 6-32 X 1/2 PAN QUAD MS TIN PLATED

1

5234 470N 63V 10%CAP T&R RAD .2FLM

6

8581 CUSTOM PBL TRANSISTOR SPACER

2

8796 6-32 X 5/8 PAN PH TAPTITE ZINC

9

5266 680N 250V 20%CAP BLK 'X2' 27MM AC

2

5299 24AWG SOLID SC WIR RAD JMP

2

8828 6-32 X 3/4 PAN PH TAPTITE JS500

2

2305 __1U 400V 10%CAP BLK RAD POLY FLM

2

4660 5.0W 0R047 5% BLK RES

2

8823 6-32 X 1 PAN PH TAPTITE JS500

2

5254 __1U 63V 20%CAP T&R 4X7MM .2EL

2

4682 1/2W 1R 5%PHILIPS SMAL T&R RES

2

8744 6-32 X 1 1/4 HH MS UD ZINC

4

5256 __1U 63V 5%CAP T&R RAD .2FLM

2

4703 2.0W 2R 5% T&R RES

8

8803 8-32 X 3/8 PAN PHIL TAPTITE JS500

6

5262 __1U 275V 20%CAP BLK 'X2'26.0MM AC

1

4911 1/4W 2R2 5% T&R RES

3

8849 8-32 X 1 PAN PHIL MS TIN PLATED

2

5953 __3U3 250VDC10% CAP BLKRAD POLYPFLM

5

4748 2.0W 3R9 5% T&R

6

8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK

16

5954 __3U3 400VDC10% CAP BLKRAD POLYPFLM

1

2010 1/6W 10R0 2%FLAME PROOF T&R RES

8

8780 5/16-18 X 3 3/4 CARRIAGE BOLT FT ZN

1

5258 __4U7 63V 20%CAP T&R 8X7MM .2EL

4

2037 1/4W 10R FUSIBLE T&R RES

6

9404SS 1/4-20X23MM SS JOINT CONN BOLT BO&W

8

5260 _22U 50V 20%CAP T&R RAD .2EL

4

2039 1/4W 22R0 FUSIBLE T&R RES

4

9419SS 1/4-20X11/4 SS TRUSS PH MS B.O.&WAX

16

5265 _68U 25V 20%CAP T&R RAD .2EL

2

2319 2.0W 33R 5% MIN FUSIBLE T&R RES

2

9407SS 1/4-20 X 1 3/4 SS FLAT PHIL MS BO&W

6

5879 100U 16V 20%CAP T&R 8X7MM .2EL

1

4817 1/4W 47R 5% T&R RES

1

4088 IEC POWER V-LOCK INLET

1

5880 100U 35V 20%CAP T&R 8X11MM .2EL

2

2019 1/8W 100R0 1%FLAME PROOF T&R RES

1

3744 SNAP IN .375 SPACER RICHCO

9

5621 470U 63V 20%CAP BLK 12X25MM EL

2

4857 1/4W 220R 5% T&R RES

5

8691 6X3/8" ROUND ALUMINUM SPACER

3

5635 1000U 35V 20%CAP BLK RADIAL ELECT

1

4821 1/4W 470R 5% T&R RES

2

4007 CUSTOM .9 LED SPACER

3

5857 4700U 160V 20%CAP RAD 40X63MM 5PIN

4

4980 1/4W 470R 5%MINI T&R RES

1

8681 4-40 X 0.94" HEX SPACER ALUMINUM

3

2339 _10K B LIN 12MM DUAL 21DET P34

1

4743 1/4W 681R 0.1% *** T&R RES

2

7447 15" 8R 1000WPGM SPEAKER

2

3606 12.00 AMP CIRCUIT BREAKER

1

4981 1/4W 1K 5%MINI T&R RES

5

8482 3/8 1D FLAT WASHER

2
