M1472 PRODUCTION NOTES
1. RTV MUST BE ADDED TO R3 AND R5 BEFORE THEY
ARE INSERTED INTO THE BOARD (SEE ASSEMBLY DRAWING)
2. RTV MUST BE ADDED GENEROUSLY TO THE TOPS OF
R3 AND R5 BEFORE BULBS B1, B2, B3, AND B4 ARE
INSERTED (SEE ASSEMBLY DRAWING)
3. RTV MUST BE ADDED TO THE FOLLOWING CAPS
C2, C3, C4, C5, C6, C7
4. RTV MUST BE ADDED TO THE FOLLOWING INDUCTORS
L2, L3, L4, L5, L6
5. RTV MUST BE ADDED TO THE FOLLOWING RESISTORS
R1, R2, R4, R6, R7, R8
6. AFTER WAVE SOLDERING, BREAK OFF INCORRECT BOARD NUMBER
TAB AT BOTTOM EDGE OF THE PANEL AS INDICATED ON DRAWING (BREAK ME)
7. TIE-WRAP L4, L5, L6, C4, C5, C6 USING ROUTING/HOLES ON BOARD
8. BOLT L2 TO BOARD USING 3853, 3515, AND 3855. 3853 MUST BE INSERTED
FROM TOP OF COIL (3855 MUST BE ON BOTTOM SIDE OF BOARD)
9. BOLT L3 TO BOARD USING 3854 AND 3855
SEE LAYOUT DIAGRAM
12
9
6
3
#
13
11
10
5
4
8
7
2
1
DATE
MODEL(S):-
VER# DESCRIPTION OF CHANGE
D
D
V
V
N
N
D
D
D
D
May 2009
V
V
V
V
1.00p0
N
N
N
N
First Prototype
X8015 PCB HISTORY
N4/E502
June 2009 1.00p1 Second Prototype; Added 1/4" for Elite, value changes
JULY 2009 1V00 First Production Issue
20-JAN-2010 2V00 PC7943: Add material under W1, W2, W3. Rounded corners.
25-JAN-2010 . PC7974: Replace capacitors C4, C5, C6 from #5444 to #5450
C2 from #5644 to #5447; C7, C17 from #5960 to #5449 . .
. . PCxxxx: Add R9 #6536 GG
5
2
#
6
3
4
1
DATE
MODEL(S):-
VER# DESCRIPTION OF CHANGE
D
D
V
V
N
N
D
D
D
D
V
V
V
V
N
N
N
N
N4/E502
X8015 PCB DRILLING HISTORY
PCB
3764
3853
3855
3515
PCB
3746 Bulbs (4)
10 Watt Resistors
RTV between bulbs
and resistors.
RTV between resistors
and PCB.
