Parts list – Yorkville E1152 User Manual
Page 3
E1152 Parts List 5/17/2010
YS No. Description
Qty.
YS No. Description
Qty.
5447 __3U3 200VAC 10% CAP AXL POLY FLM
1
5449 __6U8 250VAC 10% CAP AXL POLY FLM
1
5450 _20U 250VAC 10% CAP AXL POLY FLM
3
5849 _15U 240V 10%CAP BLK RAD POLYP FLM
1
5853 _75U 140V 5%CAP BLK AXL POLY FLM
1
3813 _430UH COIL 18AWG R000 BOBBIN
1
3764 1300UH COIL 14AWG R280 AIR CORE
1
3712 1600UH COIL 18AWG R225 IRN CORE
1
2301 2.4MH COIL 16AWG R560 AIR CORE
1
3875 4000UH COIL 17AWG R??? IRN CORE
2
8467 2X2-IB-3/8" FLYING HARDWARE BRACKET
4
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK
1
8547 PLASTIC FOOT BLACK, POLYETHYLENE
4
8562 CORNER, 3 LEGS, BLACK POWDER COAT
4
8569 CORNER,2 LEGS/NO LIP BLACK POWDER C
4
3924 1/4" JCK PCB MT VERT 2XTIP HICURNT
2
3628 SPKON 4C PCB MT VERT 250TAB GRY #4
2
3451 EYELET SMALL 0.089 OD PLATED
4
6536 JN2R-A5L GAS DISCHARGE TUBE 350V
1
8565 BAR HANDLE ALL METAL RECTANGULAR
2
7495 _8R 220W 1.40" DRIVER TIDE920TNB&C
1
3853 1/2-13X 2" NYLON HEX SCREW
1
3854 1/2-13X1.5" NYLON HEX SCREW
1
3855 1/2-13 NYLON HEX NUT
2
8721 3/8-16X11/4 GRD5 FLAT SCKT HD JS500
10
9897 CABINET COVER, BLACK, 54" WIDE
21.08
3803 NYLON SECUR-A-TACH MINI PLASTIC TIE
1
4066 4 PIN 0.156 WAFER 0.809 MATE LENGTH
2
3903 PCB CONN 4 CIR BOTTOM .156
2
4096 CONN PLUG 4 POS. .084" V-2 FEMALE
1
3543 20 PIN BRKAWAY 90 LOCK .156
0.75
3538 24 PIN BREAKAWAY LOCK .156
0.743
4151 4 PIN POWER PIN HEADER
1
3576 CON TERM FENALE 14-20 AWG
4
8259D LOGO ELITE SERIES LARGE DOMED
1
3746 12V8 27W WIRELEAD SK3CWT3 BULB
4
8800 6-32 KEPS NUT ZINC
2
8858 6-32 PEMNUT W/NYLON LOCK .265 HOLE
2
8604 10-32 T NUT
16
8602 1/4-20 T NUT
4
8890 1/4-20 CAGE NUT C79-88142027
4
8724 3/8-16 T-NUT (SCREW MOUNT)
2
4711 15.W 3R9 10% BLK RES
2
4706 10.W 22R 5% BLK RES
2
4858 25.W 22R 10% BLK RES
3
5023 15.W 33R 5% BLK RES
1
3049 PATCH 04 18AWG 15.0 156
1
8729 #4 X 3/8 FLAT QUAD TYPE A JS500 BLK
4
8807 6-32 X 5/16 PAN PH MS JS500
3
8829 6-32 X 3/8 FLAT PH TAPTITE BO#C HEA
3
8836 6-32 X 3/8 TRUSS PHIL MS B/O & WAX
2
8806 6-32 X 1/2 PAN PH TAPTITE JS500
2
8811 #6 X 1 1/4 FLAT HD SQ SCKT WS ZN CL
80
8785 #8 X 3/4 OVAL PH TYPE A BLACK OXIDE
28
8756 #10 X 3/4 PAN PH TYPE A BLACK OXIDE
46
8781 #10 X 7/8 FLAT QUAD TYPE A JS500BLK
4
8727 #10 X 1" PAN PH TYPE A JS500 BLACK
4
8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK
16
8928 #14X11/4 ALLEN FLHD WOOD SCRW JS500
4
8935 1/4-20 X 23MM JOINT CON. BOLT B/O
2
8847 1/4-20 X 1 1/4 FLAT PH MS JS500
6
8846 1/4-20 X 1 3/4 FLAT PH MS JS500
4
8730 M6 X 16 HEX BOLT ZINC
4
4065 5/8 PLASTIC HEX SPACER #6
3
7496 15" 4R 800WPGM SPKR NEO
1
7494 HORN 1.4" 60X50 CD HORN
1
8972 3/16" CROSSOVER PLATE FOAM
1
8489 1/4-20 SPLIT WASHER BLACK OXIDE
4
8482 3/8 1D FLAT WASHER
1
8488 3/8 INT TOOTH LOCKWASHE ZINC
1
3515 NYLON SHOULDER WASHER (SWS 4003)
1
3407 4PDT SLID SW PCMT V GOLD CONTACTS
2
3050 PATCH 06 18AWG 15.0 156
1
3051 PATCH 08 18AWG 15.0 156
1
