NX720S Parts List 8/15/2012
YS # Description Qty. YS # Description Qty. YS # Description Qty.
6405 RED 3MM LED 2V0 20MA BRT 1 4063 1/4IN ISO JCK PCMT VT STER RT SWT 2 4901 1/4W 13K 5% T&R RES 1
6400 YEL 3MM LED 1V9 6MA HIGHEFF 1 4010 XLR FEML PCB MT VERT 24MM AA-SERIES 2 4775 1/4W 14K0 1% T&R RES 1
6408 GRN 3MM LED 1V9 5MA FROSTED 1 4100 XLR MALE PCB MT VERT 2 4979 1/4W 15K 5%MINI T&R RES 2
6825 1N4148 75V 0A45 DIODE T&R 24 2899 STANDARD FERRITE CORE 1 4784 1/4W 17K40 0.1% *** T&R RES 2
6892 UF4004 200V 1A0 DIODE ULTRAFAS 1 8565 BAR HANDLE ALL METAL RECTANGULAR 2 5021 1/4W 18K7 1% T&R RES 2
6438 1N4007 1000V 1A0 DIODE T&R 6 3501 B52200F006 COMP WASH #4 SMALL 9 6123 1/4W 20K0 1%MINI MF T&R RES 2
6421 MR752 200V 6A0 DIODE 4 3979 6POS XSISTOR TO220SPRING 1 6118 1/4W 22K 5%MINI T&R RES 10
6733 BAT85 30V 0A2 DIODE SCHT T&R 6 3803 NYLON SECUR-A-TACH MINI PLASTIC TIE 1 4956 1/4W 27K 5% .2"U T&R RES 1
6432 1N5248B 18V0 0W5 ZENER 5% T&R 5 3810 4" NYLON CABLE TIE 8 6122 1/4W 33K 5%MINI T&R RES 2
6440 1N750ARL 4V7 0W5 ZENER 5% T&R 2 3841 5.5" NYLON CABLE TIE 2 4686 1/4W 37K4 1% METAL FILM T&R RES 3
6461 1N5240BRL 10V0 0W5 ZENER 5% T&R 1 3558 TERM HOUSING 4 CIR .156/RAMP 1 4878 1/4W 43K 5% T&R RES 1
6818 1N5245B 15V0 0W5 ZENER 5% T&R 1 3538 24 PIN BREAKAWAY LOCK .156 0.167 6119 1/4W 47K 5%MINI T&R RES 7
6728 MC78L05ACP TO92 P 5V0 REG TR V4 1 4146 3 PIN POWER PIN HEADER MALE POLZED 1 4836 1/4W 68K 5% T&R RES 2
6871 MC7915CT TO220 N 15V0 REG V2 1 4151 4 PIN POWER PIN HEADER MALE POLZED 1 4929 1/4W 82K 5% .2"U T&R RES 1
6872 MC7815CT TO220 P 15V0 REG V1 1 4147 6 PIN POWER PIN HEADER MALE POLZED 2 4942 1/4W 100K 5% .2"U T&R RES 2
5103 MPSA06 TO92 NPN TRAN T&R TA 1 3549 TRIFURCON TERM .156 4 6120 1/4W 100K 5%MINI T&R RES 8
5107 2N5551 TO92 NPN TRAN T&R TA 4 8637 ROUND PUSH BUTTON 1/4" BLK 24MM 1 4776 1/4W 113K 1% T&R RES 2
5108 2N5401 TO92 PNP TRAN T&R TA 3 8653 LOW PROFILE POINTER AT 12 KNOB 3 4638 1/2W 150K 5% T&R RES 1
5114 MPSA92 TO92 PNP TRAN T&R TA 2 3426 8' 3/16 SJT AC LINE CORD REMOVB-CSA 1 4841 1/4W 220K 5% T&R RES 1
5105 MPSA13 TO92 NPN DARL T&R TA 2 240D LOGO YORKVILLE SMALL BLUE DOMED 1 6126 1/4W 220K 5%MINI T&R RES 2
6967 IRFP23N50L TO247 NCH MFET TM 2 792CORE 77091-A7 KOOL-MU TOROID CORE 1 6127 1/4W 470K 5%MINI T&R RES 4
6542 LM318 IC OP AMP 1 3792 _288UH CHOKE 89T20AWG/77091MAGNTKS 1 6106 1/4W 620K 5%MINI T&R RES 1
6804 MC33079P IC QUAD OP AMP 1 8800 6-32 KEPS NUT ZINC 3 4844 1/4W 1M 5% T&R RES 2
6840 MC33078P IC DUAL OP AMP 2 9931 6-32 NYLON INSERT LOCK NUT 30 4948 1/4W 1M 5% .2"U T&R RES 5
6882 TL072CP IC FET DUAL OP AMP 9 8854 6-32 X 1/4" 0.D. HEX NUT ZINC CLEAR 2 4845 1/4W 2M2 5% T&R RES 1
6884 NE5532N IC DUAL OP AMP 2 8787 8-32 KEPS NUT ZINC 4 6132 1/4W 8M2 5%MINI T&R RES 1
6640 LM311 IC VOLTAGE COMPARATOR 2 8602 1/4-20 T NUT 8 4751 1/4W 22M 5% T&R RES 1
6745 LM13600N IC XCONDUCTANCE AMP 1 8797 5/16-18 KEPS NUT JS500 1 9041 .093" HOLE .156" STAG 16GA 36"X120" 2.54
6887 IR2110 IC HILO FET DRIVER 1 4043 SIL-PAD GASKET 3.75"X.900" 1 9070 18GA ELECTRO GALV STEEL 4'X8' SHEET 0.46
6603 74HC14N IC HEX INV SCHMID 2 4089 SARCON 30GTR THERMOPAD 1.4"X4.75" 1 9141 .125" 48X96 UTILITY ALUMINUM 3.2
6605 74HC86N IC QUAD 2INP XOR 1 4599 22AWG SOLID SC WIR T&R JMP 5 9250 .040" 48X96 5052H32 KAHLUA SPARKLE 0.487
6543 48R 265V RESETTABLE THERMISTOR PTC 1 5299 24AWG SOLID SC WIR RAD JMP 2 9549 .187" 48X96 UTILITY ALUMINUM 1.233
6467 _10K 10% THERMISTOR TO-92 NTC 1 4660 5.0W 0R047 5% BLK RES 2 9818 15MM (5/8") RUSSIAN BIRCH 19
5200 _10P 200V 5%CAP T&R RAD CER.2NPO 1 4682 1/2W 1R 5%PHILIPS SMAL T&R RES 1 8842 #4 X 5/16 PAN QUAD TYPE A JS500 BLK 8
5408 _47P 100V 10%CAP T&R BEAD NPO 1 4703 2.0W 2R 5% T&R RES 1 8811 #6 X 1 1/4 FLAT HD SQ SCKT WS ZN CL 20
5199 100P 100V 2%CAP T&R RAD CER.2NPO 3 4911 1/4W 2R2 5% T&R RES 1 8756 #10 X 3/4 PAN PH TYPE A BLACK OXIDE 20
5412 220P 100V 10%CAP T&R BEAD NPO 1 4748 2.0W 3R9 5% T&R 4 8727 #10 X 1" PAN PH TYPE A JS500 BLACK 18
5194 470P 1000V 10%CAP T&R RAD CER.2Y5P 1 4813 1/4W 6R2 5% T&R RES 2 8777 #14 X 1FLAT PH TYPE A JS500 M6 HEAD 4
5201 470P 100V 5%CAP T&R RAD CER.2NPO 6 2010 1/6W 10R0 2%FLAME PROOF T&R RES 4 8906 #14X2 ALLEN FLAT HD WOOD SCRW JS500 4
5820 470P 200V 5%CAP T&R BEAD NPO 2 2038 1/4W 11R FUSIBLE T&R RES 2 8865 4-40 X 5/16 PAN PH MS JS500 5
5208 __2N2 400V 5%CAP T&R RAD .2FLM 2 6134 1/4W 47R 5%MINI T&R RES 1 8801 6-32 X 3/8 PAN PH TAPTITE JS500 16
5275 __3N3 100V 5%CAP T&R RAD .2FLM 1 2018 1/6W 75R 2%FLAME PROOF T&R RES 1 8806 6-32 X 1/2 PAN PH TAPTITE JS500 1
5209 __4N7 250V 5%CAP T&R RAD .2FLM 4 2019 1/8W 100R0 1%FLAME PROOF T&R RES 1 8835 6-32 X 1/2 PAN QUAD MS TIN PLATED 2
6451 __4N7 250V 20%CAP BLK 'Y' 10MM AC 1 4984 1/4W 150R 5%MINI T&R RES 3 8823 6-32 X 1 PAN PH TAPTITE JS500 30
5271 __5N6 100V 5%CAP T&R RAD .2F 1 4944 1/4W 220R 5% .2"U T&R RES 1 8763 8-32 X 1/2 PAN PH MS JS500 BLACK 4
5204 _10N 100V 10%CAP T&R RAD .2FLM 2 4977 1/4W 220R 5%MINI T&R RES 1 8786 10-32 X 1 1/4 PAN QD MS JS500 BLACK 8
5210 _22N 100V 10%CAP T&R RAD .2FLM 1 2024 1/6W 249R 2%FLAME PROOF T&R RES 1 8926 5/16-18X3 CARRIAGE BOLT ZINC 1
5224 _47N 100V 10%CAP T&R RAD .2FLM 2 4821 1/4W 470R 5% T&R RES 1 4088 IEC POWER V-LOCK INLET 1
5226 _68N 100V 5%CAP T&R RAD .2FLM 1 4743 1/4W 681R 0.1% *** T&R RES 2 4143 NYLON SPACER L=.312 1D=.171 OD=.375 15
5227 _82N 100V 5%CAP T&R RAD .2FLM 3 4758 1/4W 953R 1% T&R RES 1 9002 6X0.312" ROUND ALUMINUM SPACER 2
5212 100N 63V 5%CAP T&R RAD .2FLM 41 4981 1/4W 1K 5%MINI T&R RES 12 4007 CUSTOM .9 LED SPACER 3
5242 100N 250V 20%CAP BLK 'X2' 15MM AC 1 6110 1/4W 1K0 1%MINI MF T&R RES 2 8681 4-40 X 0.94" HEX SPACER ALUMINUM 3
5229 150N 63V 10%CAP T&R RAD .2FLM 5 4585 1/4W 1K2 5%MINI T&R RES 2 7537 15" 8R 1000WPRGM 3"V.C. CER SPEAKER 1
5230 180N 63V 5%CAP T&R RAD .2FLM 2 4769 1/4W 1K4 1% T&R RES 1 8482 3/8 1D FLAT WASHER 2
5231 220N 63V 5%CAP T&R RAD .2FLM 4 2034 1/8W 1K5 5%FLAME PROOF T&R RES 2 8485 #6 SPLIT WASHER ZINC 4
5233 330N 63V 5%CAP T&R RAD .2FLM 2 2051 1/4W 1K5 FUSIBLE T&R RES 3 3500 SHOULDER WASHER SWS605 5
5234 470N 63V 10%CAP T&R RAD .2FLM 1 4988 1/4W 1K5 5%MINI T&R RES 3 8818 3/4 OD X 3/8 ID X .080 THICK WASHER 1
5266 680N 250V 20%CAP BLK 'X2' 30MM AC 1 5005 2.0W 1K8 5% T&R RES 1 8820 #8 FLAT WASHER JS500 8
5254 __1U 63V 20%CAP T&R 4X7MM .2EL 1 6113 1/4W 2K 5%MINI T&R RES 3 8817 #10 FLAT WASHER FOR 3/16" BOLT 4
5255 __1U 63V 20%CAP T&R RAD .2EL 2 4847 1/4W 2K2 5% T&R RES 2 3522 DPDT MINI PC VERT SNP ALT 1
5257 __2U2 63V 20%CAP T&R RAD .2EL 1 4864 1/4W 2K7 5% T&R RES 1 3585 DPDT ROKR SW QUIK 250" AC/PWR IEC65 1
5949 __3U3 140AC10%CAP BLK RAD POLYP FLM 3 4936 1/4W 2K7 5% .2"U T&R RES 1 H1337U XFMR:LS701/720/750 1
5951 __3U3 250DC10%CAP BLK MPOLYP FLM 1 6136 1/4W 3K3 5%MINI T&R RES 4
5258 __4U7 63V 20%CAP T&R 8X7MM .2EL 2 4814 1/4W 3K6 5% T&R RES 2
5631 _22U 50V 20%CAP T&R 6X7MM .2EL 2 4756 1/4W 4K12 0.1% *** T&R RES 3
5961 _33U 16V 20%CAP T&R RAD .2IN NP 2 4774 1/4W 4K12 1% T&R RES 2
5879 100U 16V 20%CAP T&R 8X7MM .2EL 1 4943 1/4W 4K7 5% .2"U T&R RES 2
5887 2200U 50V 20%CAP BLK 18X27MM EL 2 4982 1/4W 4K7 5%MINI T&R RES 3
5862 3300U 180V 20%CAP RAD 40X50MM 5PIN 2 4939 1/4W 5K1 5% .2"U T&R RES 1
2339 _10K B LIN 12MM DUAL 21DET P34 3 6138 1/4W 5K1 5%MINI T&R RES 1
2401 4.0 AMP CIRCUIT BREAKER H-NUT 1 4717 1/4W 6K19 1%MINI T&R RES 1
3899 __18UH MINI INDUCTOR HI-Q T&R 4 4978 1/4W 6K8 5%MINI T&R RES 5
6492 1300UH COIL COMMON MODE 4AMP 1 6112 1/4W 9K09 1%MINI MF T&R RES 1
8483 ADAPTOR,SPEAKER STAND,METAL,BLACK 1 4762 1/4W 9K760 0.1% *** T&R RES 2
8545 RECESSED RUBBER BUMPER WITH WASHER 4 5016 1.0W 9K760 0.5% *** T&R RES 4
C1258 M1485 SPACER BAR MADE IN CHINA 1 4940 1/4W 10K 5% .2"U T&R RES 8
3485 CLIP 250X032 18-22AWG RIGHT ANGL 2 4983 1/4W 10K 5%MINI T&R RES 4
3489 CLIP 250X032 18-22AWG DISCO/INSL 1 6116 1/4W 10K0 1%MINI MF T&R RES 1
3490 CLIP 250X032 14-16AWG DISCO/INSL 8 4768 5.0W 12K 5% BLK RES 5
3601 RING TERMINAL 16AWG WIRE & #8 SCREW 1 4856 1/4W 12K 5% T&R RES 2
