22
Parts List
Pump Parts
29501 MOTOR-LEESON 2HP 230V
29507 MOTOR-LEESON 2HP 208V
26572 FAN-BALDOR MOTOR
29743 PUMP WITH MOTOR, IMPELLER AND CASING GASKET (W/B 2HP)
21356 FRAME ADAPTOR WITH WEAR RING
22446 SHAFT SLEEVE
25976 SNAP RING
21884 IMPELLER
25975 IMPELLER KEY
19345 GASKET-PUMP CASING (W)
24463 SEAL KIT-PUMP
RS1011 PUMP CLEANOUT PLUG
Control Panel Parts
103-052 SCREW-CONTROL PANEL (2)
23949 GASKET-CONTROL PANEL
23894 START SWITCH-PUSH BUTTON
23895 STOP SWITCH-PUSH BUTTON
23896 SWITCH BLOCK-STOP
23727 SWITCH BLOCK-START
29444 CONTACTOR
24223 TIMER
24224 SOCKET, TIMER
19885 LIQUID LEVEL CONTROL
21473 SOCKET, LIQUID LEVEL CONTROL
21472 HOLD DOWN CLIP, LIQUID LEVEL CONTROL (2)
23579 FUSE BLOCK, MAIN
23580 MOUNT-FUSE BLOCK
RS1471 GROUDING BLOCK
20281 FUSE BLOCK, CONTROL CIRCUIT
20642 FUSE 1 BUSSMAN LP-CC-20 (2)
20280 FUSE 3 BUSSMAN ABC 2
29939 OVERLOAD
27833 #10-24 THREADED STUD (6)
103-020 HEX NUT ¼” X 20 (6)
103-014 NUT SERT #10-24 (2)
Miscellaneous Parts
23987 LIQUID LEVEL SENSOR
23988 GASKET – LIQUID LEVEL SENSOR
24853 INTAKE BAFFLE 28” ( SERIAL #’S 1350 AND UP )
24860 INTAKE BAFFLE 25” ( SERIAL #’S 1350 AND UP )
100-343 "O" RING - LEVER DRAIN
