AUX IN
-29-
Front Input AUX Operation
On the front panel of this unit, there is an
AUX IN jack, follow the diagram below to
connect analogue replay devices(only
for the Audio connect, if you want to
connect the Video, please plug the RCA
on the back of the unit .) .
Use this jack to replay sound of other
replay equipment such as Digital Video
players, computers, etc. Via the loud
speakers.
-
3). You now hear the sound from the
external device played back through
the loudspeakers .
4). Touch the volume+/- sections on
touch screen or use the VOL+/- on
the panel to adjust the volume level.
Touch Screen Operation
Function
zone
To return to the main menu
2). In any mode, press the “MOD” button
on the front panel to select AUX mode .
1). Please connect the external device
with stereo jack plug the Aux in socket .
AUX IN
AUX IN JACK FRONT PANEL
MOD
VIDEO IN (yellow)
RCH IN (red)
LCH IN (white)
