Installation/Operation Supplement
7 9002062 (EN)
Figure 1
CFD21N
1 Hot Water Connections .75 in. (19 mm) 5 Ventilation Tub
2 Cold Water Inlet (required) .75 in. (19 mm) 6 Drain Outlet
3 Power Input 7 Cold Water Inlet (required) .75 in. (19 mm)
4 Emergency Stop Button 8 Fill and Supply Ventilation
H
CFD21N 18 MODEL
40.9 in.
(1038 mm)
39.8 in.
(1011 mm)
26 in.
(660 mm)
9.1 in.
(231 mm)
6 in.
(153 mm)
3 in.
(75 mm)
5.5 in.
(139 mm)
27.7 in.
(633 mm)
31.9 in.
(809 mm)
26 in.
(660 mm)
8
1
2
6
14.4 in.
(365 mm)
8.7 in.
(220 mm)
33.2 in.
(843 mm)
4
3
5
20.9 in.
(530 mm)
2.8 in.
(70 mm)
7 in.
(180 mm)
7.2 in.
(184 mm)
2.6 in.
(65 mm)
2.6 in.
(65 mm)
2.7 in.
(69 mm)
26.3 in. (670 mm)
28.6 in. (727 mm)
7
