11 P/N 1010807 Rev. E 06/06
VERTICAL CONTACT TOASTER
MAINTENANCE
Daily
CLEANING THE RELEASE SHEET, THE OPTIONAL BELT
WRAPS, CONVEYOR BELT CHAINS, AND TOASTER
Tools Required:
• Heat resistant gloves
• Clean towels
• Multipurpose Detergent Solution
• Sanitizer Solution
1. Turn the Rocker Switch (power On/Off) to OFF,
unplug the power cord, and allow the unit to cool
for 30 minutes.
2. Put on heat resistant gloves. Remove the Bun
Feeder, Heat Shield, and Bun Chute (Figure 1).
Wipe them with a damp sanitized towel and allow
them to air dry.
3. Remove the Release Sheet and place it on a
clean, flat dry surface. Wipe the silver side with
a clean towel dampened with Multipurpose
Detergent Solution immediately followed by a
second clean towel dampened with sanitizer and
allow it to air dry before continuing. Repeat this
step on the reverse side of the Release Sheet.
4. Open the front Conveyor Cover and firmly wipe
the Belt Wrap (if used) or Conveyor Belt Chain
from left to right and top to bottom with a clean
towel dampened with Multipurpose Detergent
Solution immediately followed by a second clean
towel dampened with sanitizer solution.
CAUTION
Turn the unit off, disconnect the power source and
allow the unit to cool down 30 minutes before per-
forming any service or maintenance on the unit.
CAUTION
To prevent damage to the unit, do not use abrasive
cleaners on the Release Sheet or belt wrap.
CAUTION
Failure to use Release Sheets may result in damage
to the unit and loss of warranty coverage.
5. Close the front Conveyor Cover, open the rear
Conveyor Cover, and clean the Belt Wrap (if
used) or Conveyor Belt Chain as described in
Step 4.
6. Close the rear Conveyor Cover, Reinstall the
Heat Shield, plug in the power cord, turn the unit
on, count 10 seconds, then turn the unit off and
unplug the unit. This will allow the uncleaned
sections to be exposed.
7. Open the rear Conveyor Cover again, clean the
newly exposed section of the Belt Wrap (if used)
or the Conveyor Belt Chain in the same manner
as before. Close the Conveyor Cover.
8. Open the front Conveyor Cover again and clean
the newly exposed section of the Belt Wrap (if
used) or Conveyor Belt Chain in the same man-
ner as before.
9. Close the front Conveyor Cover and wipe down
the outside of the toaster with a clean, damp,
sanitized towel.
10. Install the Release Sheet, using the reverse side,
by draping it over both sides of the Platen with
the crease centered on the Platen.
NOTE: Rotate from side to side daily or weekly to
prolong the life of the Release Sheet.
11. Install the Bun Chute so the hooks are installed
over the lower rear yellow Support Rod. Install
the Heat Shield with the Release Sheet retainer
clips securely over the Release Sheet and Platen.
12. Reinstall the Bun Feeder and plug in the unit.
Important! Make sure the Heat Shield is activat-
ing the Conveyor Safety Interlock Switch. The
Conveyors will not rotate unless the Heat Shield is
in place and the Conveyor Safety Interlock Switch
is activated.
Note: Check the Release Sheet to make sure it
is not caught in the Conveyor. Additional release
Sheets can be obtained through your Authorized
Service Agency under P/N 7000249 (3 Pack) or
7000250 (10 Pack).
