4
SECTION II
FEATURES
A. Dependable Microprocessor Solid State Integrated Circuitry – To eliminate as many moving parts as
possible.
B. Sensor Activated Fire Extinguishing (S.A.F.E.) System – A feature, which continually monitors the
basket (tumbler) for fires. In the event of a fire, a water supply to the basket (tumbler) will suppress the fire.
The Phase 7 dual microprocessor controller (DMC) computer will also notify the user that a fire has taken
place.
C. Program Changes are Easily Made at the Keyboard (Touch Pad) – Actual programs are viewed at the
liquid crystal display (L.C.D.) startup or verification.
D. Temperature Selections – Accommodates three (3) temperature settings: “HI” , “MED” , and
“LO” , each programmable to a drying temperature between 100°F (38°C) and 190°F (87°C) for radial
airflow or 100°F (38°C) and 150°F (66°C) for axial airflow.
E. Cool Down – Cool down lowers the temperature in the basket (tumbler) to make the material cool enough
to handle.
F. L.C.D. – Informs user of cycle status and programs; displays important diagnostic and fault codes.
G. Wrinkle Guard Program – Helps keep items wrinkle-free when they are not removed from the dryer
promptly at the end of the drying and cooling cycles.
H. Diagnostics – Major circuits, including the door switch(es), microprocessor temperature sensor, heat output
circuits, and more are individually monitored, allowing for precise messages of your failure.
I. Audio Alert Signal – The tone will sound at the end of a complete drying cycle at a 1-second rate for the
duration programmed. It will also sound for any fault conditions at a quarter-second rate for 4-beeps.
Finally, there is a 3-beep warning at the beginning of every Wrinkle Guard On Cycle, and a continuous rapid
pulse is used for the entire duration of S.A.F.E. system activation.
J. Temperature Conversion Status – Temperature-related programs can be set in either Fahrenheit (°F) or
Celsius (°C). ALL temperatures will automatically convert to the corresponding values (+/- 1°) when
changes are made.
K. High Temperature Protection – If the Phase 7 DMC (computer) senses that the temperature in the basket
(tumbler) has exceeded 180°F (82°C) for axial airflow or 210°F (98°C) for radial airflow, it will end the drying
cycle, and a fault code will be displayed indicating an overheating problem.
L. RPM – The Phase 7 DMC (computer) monitors the speed of the basket (tumbler) rotation.
M. Clean Lint – This feature notifies the user when the lint access should be cleaned.
N. Language Selection – The Phase 7 DMC (computer) has the ability to display various languages.
