Page 3

3
AV1/ TV
PC IN
SLOT1
SLOT2
SLOT3
SLOT3
AV
Applicable Signals
Applicable Signals
PAL B,G,H,I
NTSC M
SECAM
NTSC4.43
PAL M
PAL N
PAL60
CVBS input
ý
Colour Systems
Input signal can be displayed
AV / Component / RGB / input signals
Display
Scart Terminal Board
Installed into display
VCR / DVD / Satellite Receiver
English
SLOT2
AV
Slot Nos. of the display unit that are compatible with terminal board attachments.
Connection
Scart socket information
AV1 IN Scart socket
【
RGB,VIDEO, S VIDEO
】
Suitable inputs for AV1 IN include RGB ( Red / Green / Blue ).
AV1 IN - Pins 15 and 20 are dependent on AV1 IN S-VHS /
VIDEO switching.
Socket Earth
- -
CVBS earth
S-C/Red in
Earth (video)
Green in
Earth (video)
Blue in
Blue earth
- -
- -
Y/Video in
Earth (video)
Status RGB
Earth (video)
- -
- -
Status CVBS
Audio in (L)
Audio earth
Audio in (R)
2 slots model
Slot1, Slot2
3 slots model
Slot1, Slot2 ( Slot3 is not compatible )
