4-4
N9360A Multi UE Tester Quick Reference Guide
4
GSM System
3
Rotate the knob to place the cursor in one of the Pass/Fail
cells on the detail screen or test result cells on the value
screen. Then, press the knob.
4
One of the following measurement result screens is displayed
according to your selection in step 3.
•
To print the measurement results or to save them into a
USB memory device, press the Print Screen softkey.
•
In the graphical display, you can use the marker function
to read data points by rotating the knob.
•
The zoom function is available on the power ramp graph
display by pressing the Zoom Off/On softkey.
Figure 4-3 Various [Automatic Test: Stand-by] Screens
5
To display other measurement result screens or to finish
analysis, press the Return softkey to display the previous
screen.
Sensitivity
RX Quality
RX Level
Phase Error
Frequency Error
Burst Timing
Power Ramp
Peak TX
Power
