8 9
■
Top view
■
Front view
■
Side view
Power cord length: approx. 1.2 m (Sheath length: approx. 1.1 m)
(measurement: mm)
Intake vent Exhaust vent
206
536
207
607
296
ш210
ш150
ш210
ш150
Cooking
zone
557
66 57
■
Top view
■
Front view
Power cord length: approx. 1.2 m (Sheath length: approx. 1.1 m)
(measurement: mm)
773
ш150 ш150
ш210 ш260 ш210 ш210
ш150 ш150
296
536
207
206
462
Cooking
zone
Dimensions
66 57
723
KY-B64BX / KY-B64BG KY-B84BX / KY-B84BG
■
Side view
25
9
487
Intake vent Exhaust vent
Rear side Front side Rear side Front side
English
25
9
487
