Power switch 1 power switch
Power conn 1 power connector
SW reset Through system configurator to execute the SW reset
Mechanical
Dimension 210 X 155 X 41 (mm)
Material SPCC
Certification CE, FCC class A, UL
Environmental
Operating temp 0 degree C ~ 50 degree C
Storage temp -20 degree C ~ 60 degree C
Water/dust
resistance
IP65 for front bezel
SPC-57E
System kernel
CPU Intel PXA-255 200MHz on board
OS Windows CE .NET 4.2
SDRAM 64MB SDRAM on board
Flash N/A for SPC-57E. Users have to get CF card by themselves to store
the image file and boot from CF card
WDT PXA-255 internal
RTC HT1381, backup by internal backup battery
Boot loader 1MB AMD Flash ROM for boot loader
Display
LCD 5.7” STN QVGA 320 x 240
Touch screen 4 wire resistant touch screen
VGA chip PXA-255 internal
I/O
RS-232 Full 9 pin RS-232 X 3; Pin headers output X 3
RS-485 RS-485 X 1, Pin headers output X 1
RJ-45 10/100 base-T Pin headers output X 1
USB USB host X 2; USB client X 1; Pin headers output
PCMCIA PCMCIA slot type II X 1
CF CF slot type II X 1
Digital I/O 8 DI & 8 DO. Pin header output. Provide API to access DIO
GPIO 8 GPIO. Pin header output inside the case. Default as hotkey
Audio Pin headers output
