Dimensions – A.O. Smith BFC - 50 User Manual
Page 3
BFC 80-100
BFC 28-60
Cyclone BFC
Dimensions
A 1390
1910
1910
1910
2060
2060
C -
-
-
-
530
530
D 705
705
705
705
850
850
E -
-
-
-
1000
1000
F -
-
-
-
900
900
G 80/125 100/150 100/150 100/150 130/200 130/200
H 1365
1905
1905
1905
2015
2015
Hx 265
265
265
265
310
310
Hy 375
375
375
375
440
440
K 1270
1800
1800
1800
1855
1855
M 170
160
160
160
225
225
N 1390
1910
1910
1910
2060
2060
Ny 205
205
205
205
205
205
P 170
175
175
175
290
290
R 85
75
75
75
225
225
S 900
1410
1410
1410
1425
1425
W 125
145
145
145
240
240
1
Cold water (external)
R1
1
/
2
2
Hot water (external)
R1
1
/
2
3
Gas control (internal)
Rp
3
/
4
4
Tank drain valve (internal)
3
/
4
5
T&P valve (internal)
1-11.5 NPT
6
Cleaning and inspection opening
95x70
7
Condensation drainage (internal)
Ø40 (BFC 28)
Rp 1 (BFC 30-100)
Dimensions in mm. All Cyclone BFC water heaters receive a
three years warranty on the tank and one year on parts.
BFC 28
BFC 30
BFC 50
BFC 60
BFC 80
BFC 100
