Panasonic SC-NE3 - Manual (Page 19)

19
VQT4U49
ENGLISH
Specifications
∫ GENERAL
* Prospective communication distance
Measurement environment:
Temperature 25 oC (77
o F) / Height 1 m (3.3 ft)
Measure in “MODE 1”
≥ Specifications are subject to change without notice.
Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum analyzer.
Licenses
Power consumption 14 W
Power consumption in standby mode
Approx. 0.1 W
Power consumption in standby mode
(With “NET STNBY” set to “ON”)
Approx. 4.0 W
Power supply AC 120 V, 60 Hz
Dimensions (WkHkD)
570 mmk206 mmk100 mm
(22 7 /
16
qk8 1 /
8
qk3 15 /
16
q)
Mass (Weight) Approx. 2.8 kg (6.17 lbs)
Operating temperature range
0 oC to r40 oC (r32 o F to r104 o F)
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
RMS Output Power Stereo mode
Front Ch (both ch driven)
20 W per channel (6 ≠),
1 kHz, 10 % THD
Total RMS Stereo mode power 40 W
FTC Output Power Stereo mode
Front Ch (both ch driven)
15 W per channel (6 ≠),
20 Hz to 20 kHz, 1 % THD
Total FTC Stereo mode power 30 W
∫ SPEAKER SECTION
Type 2 way, 2 speaker system (Bass reflex)
Speaker unit(s)
1. Woofer 8 cm (3 1 /
8
q)k1 per channel
2. Tweeter 2.5 cm (1q)k1 per channel
Impedance 6 ≠
Output sound pressure
83.5 dB/W (1 m (3.3 ft))
Frequency range 52 Hz to 25 kHz (s16 dB),
75 Hz to 22 kHz (s10 dB)
∫ Wi-Fi/AirPlay SECTION
Wi-Fi
WLAN Standards IEEE802.11b/g
Frequency range 2.4 GHz band
Security WEP (64 bit/128 bit), WPA TM , WPA2 TM
WPS version Version 2.0 (WEP not support)
∫ TERMINALS SECTION
AUX Terminal Stereo, ‰3.5 mm ( 1 /
8
q) jack
∫ BLUETOOTH SECTION
Version Bluetooth ® Ver.2.1 +EDR
Output Class 2 (2.5 mW)
Communication distance About 10 m (33 ft)*
Communication method 2.4 GHz band FH-SS
Correspondence profile A2DP
AirPlay, the AirPlay logo, iPad, iPhone, iPod, and iPod touch are
trademarks of Apple Inc., registered in the U.S. and other
countries.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi
Alliance.
The Wi-Fi Protected Setup Mark is a mark of the Wi-Fi Alliance.
“Wi-Fi”, “Wi-Fi Protected Setup”, “WPA” and “WPA2” are marks
or registered marks of the Wi-Fi Alliance.
MPEG Layer-3 audio coding technology licensed from
Fraunhofer IIS and Thomson.
The Bluetooth ® word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by
Panasonic Corporation is under license. Other trademarks
and trade names are those of their respective owners.
Windows is a trademark or a registered trademark of Microsoft
Corporation in the United States and other countries.
