38 RQT9778
Specifications
AMPLIFIER SECTION
RMS output power: Dolby Digital Mode
Front ch (L, R ch)
60 W per channel (6 ≠), 1 kHz, 10 % THD
Center ch (C ch)
60 W per channel (6 ≠), 1 kHz, 10 % THD
Subwoofer ch
120 W per channel (8 ≠), 100 Hz, 10 % THD
Total RMS Dolby Digital mode power
300 W
FTC output power: Dolby Digital Mode
Front ch (L, R ch)
25 W per channel (6 ≠),
120 Hz to 20 kHz, 1.0 % THD
Center ch (C ch)
25 W per channel (6 ≠),
120 Hz to 20 kHz, 1.0 % THD
Subwoofer ch
40 W per channel (8 ≠),
60 Hz to 120 Hz, 1.0 % THD
Total FTC Dolby Digital mode power
115 W
TERMINAL SECTION
HDAVI Control
This unit supports “HDAVI Control 5” function.
HDMI AV input (BD/DVD, AUX1, AUX2) 3
Input connector Type A (19 pin)
HDMI AV output (TV (ARC)) 1
Output connector Type A (19 pin)
Digital audio input
Optical digital input (TV, AUX3) 2
Sampling frequency
32 kHz, 44.1 kHz, 48 kHz
88.2 kHz, 96 kHz (only LPCM)
Audio format
LPCM, Dolby Digital, DTS Digital Surround
USB Port For service use only.
SPEAKER SECTION
Front speakers
3 way, 3 speaker system (Bass reflex type)
Speaker unit(s)
Impedance 6 ≠
Woofer 5.7 cm (2 1 /
4
q) cone type
Tweeter
2.5 cm (1q) semi-dome type
Super tweeter Piezo type
Output sound pressure 78 dB/W (1 m)
Frequency range 90 Hz to 32 kHz (`16 dB)
100 Hz to 23 kHz (`10 dB)
Center speaker
2 way, 2 speaker system (Bass reflex type)
Speaker unit(s)
Impedance 6 ≠
Woofer 5.7 cm (2 1 /
4
q) cone type
Super tweeter Piezo type
Output sound pressure 78 dB/W (1 m)
Frequency range 110 Hz to 20 kHz (`16 dB)
150 Hz to 16 kHz (`10 dB)
Active subwoofer
1 way, 1 speaker system (Bass reflex type)
Woofer 16 cm (6 1 /
2
q) cone type
Output sound pressure 80 dB/W (1 m)
Frequency range 30 Hz to 180 Hz (`16 dB)
35 Hz to 160 Hz (`10 dB)
WIRELESS SECTION
Wireless module
Frequency Range
2.40335 GHz to 2.47735 GHz
No. of channels 38
