Getting started
RQT9778 17
Drive a screw into the wall.
≥ Use the measurements indicated below to identify the screwing positions on the wall.
≥ Leave at least 20 mm (
25 /
32 q) of space above and on each side of the speaker to allow enough space for fitting the speaker.
≥ Keep the screws out of reach of children to prevent swallowing.
Front speakers
A At least 30 mm
(1 3 /
16
q)
B ‰4.0 mm ( 5 /
32
q)
C ‰7.0 mm to
‰9.4 mm
(
9 /
32
q to 3 /
8
q)
D Wall or pillar
E 5.5 mm to 6.5 mm
( 7 /
32
q to 1 /
4
q)
F Front speaker
(Rear view)
G 100 mm (3 15 /
16
q)
H 436 mm (17 5 /
32
q)
I 34 mm (1 11 /
32
q)
J Wall mounting hole








 

Center speaker
K At least 30 mm
(1 3 /
16
q)
L ‰4.0 mm ( 5 /
32
q)
M ‰7.0 mm to
‰9.4 mm
(
9 /
32
q to 3 /
8
q)
N Wall or pillar
O 1.6 mm to 2.5 mm
( 1 /
16
q to 3 /
32
q)
P Max. 3.5 mm
( 9 /
64
q)
Q Center speaker
(Rear view)
R 18 mm ( 23 /
32
q)
S 147 mm (5 25 /
32
q)
T 13 mm ( 1 /
2
q)
U 19.6 mm ( 25 /
32
q)
V 50.2 mm (1 31 /
32
q)






 




