Fan motor assembly – ADC AD-310 User Manual
Page 65
63
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
181007
1
Motor Base (256T Frame)
2
153011
4
1/2" Flat Washer
3
153026
4
1/2" Lock Washer
4
150605
4
1/2-13 x 1-1/2" Hex Head Machine Bolt
5
153004
4
3/8" Flat Washer
6
153005
4
3/8" Lock Washer
7
152005
4
3/8-16 Hex Nut
8
181006
1
25 HP 208-230/380/460 Volt 3ø 60 Hz Motor
and
190-220/380-416 Volt 3ø 50 Hz Motor
9*
100128
2
BX-50 V-Belt
10
101167
1
2B x 6.0 Pulley (for 60 Hz models Only)
101185
1
2B x 6.2 Pulley (for 50 Hz models Only)
11
101196
1
SDS x 1-5/8" Bushing
12
100709
1
3/8" x 3/8" x 3" Key
13
101150
1
SK x 1-1/2" Bushing
14
101145
1
2B x 11.0 Pulley (for 60 Hz models Only)
101201
1
2B x 9.4 Pulley (for 50 Hz models Only)
15
150606
2
1/2-13 x 2" Hex Head Machine Bolt
16
100804
1
1-1/2" Retaining Ring
17
880942
1
1-1/2" Shrouded Pillow Block Bearing
(includes illus. nos. 17 and 18)
18
170511
1
Grease Fitting
19
153011
2
1/2" Flat Washer
20
153026
2
1/2" Lock Washer
21
334206
1
Fan (Impellor/Blower) Shaft
22
100804
1
1-1/2" Retaining Ring
23
880942
1
1-1/2" Shrouded Pillow Block Bearing
(includes illus. nos. 23 and 26)
24
150606
2
1/2-13 x 2" Hex Head Machine Bolt
25
116014
1
Felt Seal
26
170511
1
Grease Fitting
27
153011
2
1/2" Flat Washer
28
153026
2
1/2" Lock Washer
29
100653
1
18" Dia. Squirrel Cage Fan
30
153065
1
Fan Washer
31
152006
2
1/2-20 Left Hand Jam Nut
32
100704
1
1/4" x 1/4" x 1-3/4" Key
33
881513
1
Tilt Fan (Impellor/Blower) Shaft Bearing Mount Assembly
34
153004
6
3/8" Flat Washer
35
153005
6
3/8" Lock Washer
36
150617
6
3/8-16 x 1" Hex Head Machine Bolt
* Replace in matched sets (both belts).
Fan Motor Assembly
for Steam Models ONLY
