18
RQT9944
Specifications
≥ Specifications are subject to change without notice.
≥ Mass and dimensions are approximate.
≥ Total harmonic distortion is measured by a digital spectrum
analyzer.
*1: “BLUETOOTH STANDBY” is “OFF”.
*2: No device is connected to the USB port before turning to
standby mode.
*3: MPEG-1 Layer 3, MPEG-2 Layer 3
∫ GENERAL
Power consumption 26 W
Power consumption in standby mode* 1, 2
Approx. 0.2 W
(When “BLUETOOTH STANDBY” is “ON”)* 2
Approx. 0.3 W
Power supply
AC 220 V to 240 V, 50 Hz
Dimensions (WkHkD)
500 mmk205 mmk92 mm
Mass Approx. 2.5 kg
Operating temperature range
0 oC to r40 oC
Operating humidity range
35 % to 80 % RH (no condensation)
∫ AMPLIFIER SECTION
Output power
RMS Output Power Stereo mode
Front Ch (both ch driven)
20 W per channel (8 ≠), 1 kHz, 10 % THD
Total RMS Stereo mode power
40 W
∫ TUNER SECTION
Preset Memory FM 30 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals
75 ≠ (unbalanced)
∫ DISC SECTION
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3* 3 )
Pick up
Wavelength 790 nm (CD)
[NORSK]
Bølgelengde
790 nm (CD)
Laserstyrke Ingen farlig stråling sendes ut
(med sikkerhets-beskyttelse)
∫ SPEAKER SYSTEM SECTION
Speaker unit(s)
Full range
6.5 cm Cone typek1 per channel
Passive Radiator
8 cmk2 per channel
Impedance 8 ≠
∫ TERMINAL SECTION
USB Port
DC OUT 5 V 1.5 A
USB Standard
USB 2.0 full speed
Media file format support
MP3 (¢.mp3)
USB device file system
FAT12, FAT16, FAT32
AUX IN
Stereo, 3.5 mm jack
∫ BLUETOOTH SECTION
Version Bluetooth ® Ver.2.1+EDR
Class Class 2
Supported Profiles
A2DP, AVRCP
Operating Frequency
2.4 GHz band FH-SS
Operation Distance
10 m Line of sight
