Page 2: Connections: connected to power pack, 8 pin din plug output connection diagram
8 PIN DIN PLUG OUTPUT CONNECTION DIAGRAM
GND
GND
1
2
3
CH. 1-12
CH. 9-12
CH. 5-8
CH. 1-4
CH. 11
CH. 12
CH. 10
CH. 9
GND
+20V
+20V
GND
+20V
CH. 12
CH. 8
CH. 7
CH. 6
CH. 5
CH. 11
CH. 9
CH. 4
CH. 3
CH. 2
CH. 1
CH. 10
GRN
GRN
TP-1201
SPECIFICATIONS:
1. POWER INPUT : DC +20V.
2. SIGNAL OUTPUT : “ON DC +10V; “OFF” DC +0V
3. WEIGHT : 29 oz.
4. DIMENSION : ( unit : inches )
1 1/8”
1 1/2”
19”
17 1/2”
CONNECTIONS:
CONNECTED TO POWER PACK:
TP-1201
A.D.J
SWITCHING PACK
TP-1201
12-CH SWITCHING PACK
A.D.J
SWITCHING PACK
A.D.J
SWITCHING PACK
A.D.J
SWITCHING PACK
A.D.J
SWITCHING PACK
A.D.J
SWITCHING PACK
TP-1201 Instructions page 2 of 2
