SM523-G |
Cup Holder Mount with Flexible Goosneck Shaft with Slim-Grip™ for Smartphones
(iPhone device
not included)
E
D
Secure holder with your hand for support, as spring-loaded
mechanism requires significant force to operate. Hold your
phone and insert into universal holder by pushing down on the
bottom spring-loaded support legs with moderate amount of
pressure (D). Slide the top of the device under the top support
legs (E) until it fits snuggly in the holder.
Insert Phone into Holder
Step 1.
Adjusting Holder to Fit Phone
F
F
If necessary, adjust the support legs (F) on top and bottom by
sliding them laterally to avoid any buttons or ports that may be
on your phone.
Step 1.
!
Safety Precautions
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
The Mobile Mounting Specialists™
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in Taiwan & China
© Copyright 2010 Arkon Resources, Inc.
Consumer Hotline:
USA (800) 841-0884
INT’L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
Fitting for Larger Phones
For larger phones such as the T-Mobile G2 and Motorola Droid X,
install the two included extra long support legs
A
A
B
Step 1. Insert the extra long support legs (A) by sliding them into the
support leg grooves (B) on the top and bottom of the holder.
Secure holder with your hand for support, as spring-loaded
mechanism requires significant force to operate. Hold your
phone and insert into universal holder by pushing down on the
bottom spring-loaded support legs with moderate amount of
pressure (C). Slide the top of the device under the top support
legs (D) until it fits snuggly in the holder.
Insert Phone into Holder
D
Step 1.
