41
Pre-defined lens types are:
Display:
Lens set:
UP
ARRI Zeiss Ultra Primes
VAr P
ARRI Zeiss Variable Primes
HS 35
ARRI Zeiss High-speed lenses for 35mm film
Std35
ARRI Zeiss Standard lenses for 35mm film
HS 16
ARRI Zeiss High-speed lenses for 16mm film
User
lens previously defined by the user
• Select the required lens set using the handwheel.
Then press the SEL button. The focal length then
appears in the second line of the display.
• Select the focal length using the handwheel.
Confirm the selection by pressing the SEL button.
• The display now shows the command ‘DO CAL’.
Start the calibration by pressing the CAL button on the
WMU-1
➪ photo
.
CAL button
Controlling the Iris
