Agri-Fab 45-02103-101 User Manual
Page 13
13
REPAIR PARTS FOR BROADCAST SPREADER MODEL 45-02103-101
*Purchase common hardware locally.
REF.
PART
QTY.
DESCRIPTION
NO.
NO.
31
48934
1
Hairpin, Agitator
32
43088
16
Washer, Flat 1/4" Std.
33
44468
1
Sprocket - 6 Tooth
34
44514
1
Rod, Flow Control
35
23525
2
Brace, Hitch
36
23780
1
Support, Shaft
37
44482
2
Grip, Handle
38
46055
1
Pin, Spring 1/8" Dia. x 1" Lg.
39
1543-69
14
Washer, Nylon
40
R19111116
20
Washer, 5/16 SAE
41
24858
1
Stop, Adjustable
42
24855
1
Bracket, Flow Control Mount
43
48888
1
Gear
44
24856
1
Flow Control Arm
45
44101
1
Cotter Pin 3/32" x 3/4" Lg.*
46
23533
1
Plate, Closure
47
44950
3
Bolt, Carriage 1/4-20 x 3/4" Lg.
48
43848
1
Grip, Flow Control Arm
49
44481
1
Cap, Vinyl
50
48499
2
Hub Cap
51
47141
1
Nylon Wing Nut, 1/4-20
52
43962
1
Vinyl Hopper Cover
53
46119
1
Spreader Shield
54
23998
4
Shield Swivel Bracket
55
46120
2
Plastic Knob
56
47441
1
Screen
57
24125
2
Shield Bracket
58
23999
2
Angle Stop Bracket
49120
1
Owner's Manual
REF.
PART
QTY.
DESCRIPTION
NO.
NO.
1
44466
1
Hopper
2
C-9M5732
2
Pop Rivet (not shown)
3
62482
1
Ass'y, Guide Closure
4
48842
1
Tube, Frame
5
23753
1
Slide Gate Angle Bracket
6
23758
1
Slide Gate Bracket
7
43648
9
Bolt, Hex 1/4-20 x 1-1/2" Lg.*
8
24857
1
Flow Control Link
9
47189
26
Nut, Nylock 1/4-20 Thd. *
10
48841
1
Tube, Crossover
11
43661
9
Bolt, Hex 1/4-20 x 1" Lg.*
13
44566
1
Spring, Torsion
14
44590
1
Tube, Handle (Long)
15
48954
2
Wheel
16
44589
1
Tube, Handle (Short)
17
25067
1
Shaft, Axle
18
44665
2
Pin, Spring 5/32" Dia. x 1-1/4" Lg.
19
48916
1
Bushing, Axle Shaft
20
44125
4
Washer, Shim 5/8" I.D.
21
R19212016
5
Washer, Flat 5/8" I.D.
22
741-0249
2
Bearing, Flange
23
48857
2
Tube, Spacer
24
47437
1
Shaft, Sprocket
25
04367
1
Spreader Plate
26
43850
1
Pin, Spring 1/8" Dia. x 5/8" Lg.
27
44587
1
Tube, Leg Stand
28
44285
2
Bushing, Delrin 3/8" I.D.
29
1509-69
9
Bolt, Hex 1/4-20 x 1-3/4" Lg.*
30
47063
1
Pin, Cotter 5/32" x 2"
