Installing a Passive CPU Heatsink
1. Place the heatsink on top of the CPU so that the four
mounting holes are aligned with those on the retention
mechanism.
2. Install two diagonal screw and tighten them until
just snug.
3. Repeat steps 2 with the #3 and #4 screws. Make sure
all screws are snug.
