6
Installation
Choosing the right location
Install the refrigerator in a location which satisfies the following criteria:
● Where there is a main water supply line nearby
● Where the refrigerator will not be exposed to direct sunlight
● Where the refrigerator will be at a distance from heating appliances, cooking appliances and other
sources of heat
● A location which is well-ventilated and dry
● Where the floor is sturdy and level
Place a solid board underneath if the refrigerator is to be installed on top of a carpet or vinyl floor.
The board will protect the floor from becoming deformed and discoloured.
Provide clearance to allow heat to dissipate
Residual heat is always being emitted from the refrigerator while
it is operating.
Provide sufficient clearance around the refrigerator to allow this
heat to dissipate so that its cooling ability is not impaired.
Dimensions (mm): W905 × D710 × H1850
Installing the spacers
Install the spacers on the back panel of the refrigerator to
ensure the minimum amount of space required to allow the heat
generated by the refrigerator.
Spacer (accessory)
Spacers
Attach to the back panel of the refrigerator
after removing the double-sided tape's
release liner.
When the doors are completely open
900 mm 349 mm 426 mm
1675 mm
150˚ 150˚
944 mm 989 mm
When the inside drawers have been taken out
900 mm 319 mm 384 mm
1603 mm
140˚ 140˚
974 mm 1032 mm
50 mm or more
30 mm or more
25 mm or more
Installation
