Back Panel Overview
The back panel of your computer contains the ports for supplied and optional
accessories. The back panel also provides access to Giga Pocket™ Personal
Video Recorder jacks and ports. The icons on the back panel locate and identify
the ports on your computer.
Back panel
1
Mouse port
Connection for a PS/2® mouse.
2
Keyboard port
Connection for a PS/2 Keyboard.
3
Universal Serial Bus (USB) port
Connection for a compatible USB device.
4
Ethernet port
10Base-T/100Base-TX Fast Ethernet interface.
(The port marked with
(Network) is for LAN connections only.)
