18 US
2: Connecting the speakers
Before connecting the cords, be sure to
disconnect the AC power cord (mains lead).
AFront speaker A (left)
BFront speaker A (right)
CCenter speaker
DSurround speaker (left) ESurround speaker (right)
FSurround back speaker (left)
a)b)c)
GSurround back speaker (right) a)b)c)
HSubwoofer d)
13 / 32 in.
(10 mm)
DIGITAL (ASSIGNABLE)
DC5V
0.7A MAX
HDMI ANTENNA
MPORT
SIRIUS
SAT IN DVD IN BD IN OUT AM
VIDEO 1
TV
AUDIO
OUT
VIDEO
OUT
VIDEO
OUT
IN
OPTICAL
AUDIO
IN
VIDEO
IN
MONITOR AUDIO
IN
VIDEO
IN
BD
SAT
IN
DVD
IN
OPTICAL COAXIAL
SUBWOOFER
L
L
R
R L
SPEAKERS
CENTER SURROUND
FRONT A
R
SURROUND BACK/
BI-AMP/
FRONT B
AUDIO
OUT
H
F D C
A
A Monaural audio cord (not supplied)
B Speaker cords (not supplied)
E
B
B
G A
B
