DCR-DVD610
DVD Handycam® camcorder
Please visit the Dealer Network for more
information at www.sony.com/dn
Specifications
General
Imaging Device: 1/8" Advanced HAD™ CCD Imager
Pixel Gross: 680K
Recording Media: 3" (8cm) DVD (DVD-R/DVD-
RW/DVD+RW/DVD+R DL), Memory Stick Duo™ Media,
Memory Stick PRO Duo™ Media
Recording and Playback Times: Single Layer - HQ: 20
min., SP: 30 min., LP 60 min. Dual Layer - HQ: 35 min.,
SP: 55 min., LP: 110 min. When using 8GB Memory Stick
PRO Duo™ Media (sold separately): Standard
Definition: HQ = up to 115 min., SP = up to 170 min., LP
= up to 325 min.
Video Actual: 340K Pixels (4:3), 410K Pixels (16:9)
Still Actual: 340K Pixels (4:3), 250K Pixels (16:9)
Processor: N/A
Video Resolution: 720 x 480
Still Picture Resolution: 640× 480 (VGA)
Audio
Audio Format: Dolby® Digital 2 channel
Microphone: Yes (Built-in Zoom)
Convenience
USB Streaming: N/A
Accessory Shoe: N/A
White Balance: Auto, Outdoor, Indoor, One-push
(touch panel)
Memory Stick PRO™ Media Compatibility: Tested to
support up to 8GB media capacity; does not support
high speed transfer function; does not support
Access Control security function.
Still Image Mode(s): JPEG
Face Detection: N/A
Hybrid: Yes
Hybrid Plus: N/A
Quick On: Yes
Dual Record: N/A
Dynamic Range Optimizer: N/A
Scene Mode(s): Auto, Twilight, Candle (move only),
Sunrise & Sunset, Fireworks (move only), Landscape,
Portrait, Spotlight, Sports (movie only), Beach, Snow
Image Stabilization: S-SS
Convenience Features
Easy Operation: Yes
Multiple Language Display: Yes
Slide Show Mode: Yes
Picture Effect(s): Monotone, Sepia, Pastel
Digital Picture Effect(s): Old Movie
PictBridge Compatible: N/A
Low Light Capability: Super NightShot®
Fader Effect(s): Black, White
Face Index: Yes
Film Roll Index: Yes
Photo Capture from Movie: Yes
Dubbing Button: N/A
x.v.Color™ : N/A
BRAVIA® Sync™ : N/A
Video
Format: SD (MPEG2)
Video Signal: NTSC color, EIA standards
Video Features
PhotoTV HD: N/A
Inputs and Outputs
Analog Audio/Video Output(s): Included (via A/V
Remote Terminal)
USB Port(s): Hi-speed (2.0 compliant)
S-Video Output(s): Available via A/V Remote (cable not
included)
Audio/Video Remote Terminal: Yes
Display
LCD Screen: 2.7" wide (16:9) touch panel LCD display
Viewfinder: Color (123K Pixels)
Hardware
Memory Stick slot: Memory Stick PRO Duo™ Media
Manual / Auto Lens Cover: Manual
Assignable Dial: N/A
S/S & Zoom button on LCD: Yes
Light/Flash: N/A
1
Optics/Lens
35mm Equivalent: 48- 1920mm (4:3 Camera Mode), 41 -
1640mm (16:9 Camera Mode)
Aperture: F1.8 - 4.1
Exposure: Touch Panel
Filter Diameter: 30mm
Focal Distance: 1.9 - 76mm
Focus: Full Range Auto, Manual (Touch Panel)
Progressive Shutter Mode: N/A
Shutter Speed: Auto, 1/30 - 1/250 (Scene Selection
Mode)
Optical Zoom: 40x
Digital Zoom: 2000x
Lens Type: Carl Zeiss® Vario-Tessar®
Minimum Illumination: 6 lux (Auto Slow Shutter ON,
Shutter Speed 1/30)
Power
Battery Type: InfoLITHIUM® with AccuPower™ Meter
System (NP-FH40)
Power Requirements: 7.2V (battery pack); 8.4V (AC
Adaptor)
Power Consumption (in Operation): 2.7W / 2.9W
(VF/LCD)
Service and Warranty Information
Limited Warranty Term: Limited Warranty --- 1 Year Parts;
90 Days Labor
Software
Operating System Compatibility: Microsoft® Windows®
2000 Professional, XP Home, XP Professional, Windows
Vista
Supplied Software: Picture Motion Browser Ver.3.0.00
Dimensions
Weight: 15 oz (450g) with Battery
Measurements: 2 1/4 x 3 5/8 x 5 1/8 inch (55.0 x 89.0 x
130.0mm)
Supplied Accessories
Power Adapter/In-Camera Charger (AC-L200)
InfoLITHIUM® Rechargeable Battery (NP-FH40)
Multi A/V Cable (Stereo)
USB Cable
Application CD-ROM w/ Driver
Enjoy Handycam DVD
Optional Accessories
ACC-DVDH2 starter kit
BC-TRP travel charger
ECM-HW1 wireless mic.
VCT-60AV remote tripod
UPC Code: 027242727700
1. Viewable area measured diagonally.
2. Camcorder captures high definition footage in the AVCHD™ format.
Using the enclosed PC software, high definition footage can be copied
onto DVD media. However, DVD media containing AVCHD footage
should not be used with DVD based players or recorders, as the DVD
player/recorder may fail to eject the media and may erase its
contents without warning. DVD media containing AVCHD footage
may be played on a compatible Blu-ray Disc™ player/recorder or
other compatible device.
3. DVD media/formats are not universally compatible.
4. HD viewing requires a Sony HD connector cable or HD Cyber-shot
Station® cradle and HDTV. All sold separately.
5. i.LINK is a trademark of Sony used only to designate that a product
contains an IEEE1394 connection. The i.LINK connection may vary
depending on the software applications, operating system and
compatible i.LINK devices. All products with an i.LINK connection may
not communicate with each other
6. Not all products with USB connectors may communicate with each
other due to chipset variations
7. Actual battery life will vary based on product settings, usage patterns,
battery and environmental conditions.
8. Compatible BRAVIA® HDTV and special TV settings are required.
Further details are available in the BRAVIA® TV instruction manual.
9. 30GB means 30 billion bites. Available storage capacity may vary and
a portion of the memory is used for data management functions.
10. Requires BRAVIA Sync feature in each product. Please refer to
owner’s manual to determine compatibility.
