Notebook Computer User Guide 50
Connecting the Mini Docking Station
You can use the PCGA-PSX1 Mini Docking Station (optional) to connect
peripheral devices such as a printer or external display.
Back
S400 DC IN
S VIDEO / Mouse/Keyboard
VIDEO OPTICAL OUT
Monitor CONTROL A1
LINE OUT SERIAL/CONTROL A1 switch
LINE IN Serial
USB CONTROL A1
IN USE indicator
DC IN indicator
RELEASE lever
UN DOCK button Docking connector
Tabs
1 8 6 5 2 4 7 3 7
13 9 10 12 14 11
