Page 29
25
2. Technical Gas Data
a. Gas Specifications
b. Gas Connections:
Inlet connection ---------- 3/4-inch N.P.T.
Inlet supply size ---------- 3/4-inch N.P.T. (minimum)
Btu/hr input (per dryer) - 204,000
1) Natural Gas
Regulation is controlled by the dryer's gas valve's internal regulator. Incoming supply pressure must
be consistent between a minimum of 6.0 inches and a maximum of 12.0 inches water column (W.C.)
pressure.
2) Liquid Propane (L.P.) Gas
Dryers made for use with L.P. gas have the gas valve's internal pressure regulator blocked open so
that the gas pressure must be regulated upstream of the dryer. The pressure measured at each gas
valve pressure tap must be a consistent 10.5 inches water column (W.C.). There is no regulator or
regulation provided in an L.P. dryer. The water column pressure must be regulated at the source
(L.P. tank) or an external regulator must be added to each dryer.
T
YPE OF
G
AS
Natural
Liquid Propane
Manifold Pressure*
3.5 inches W.C.
10.5 inches W.C.
Inline Pressure
6.0 - 12.0 inches W.C.
10.5 inches W.C.
* Measured at gas valve pressure tap when the gas valve in on.
T
YP E OF
G
AS
L.P.
Conversion Kit
Part Number
ADC
MODEL
NUMBER
BTU
Per Hour
Rating
Natural
Liquid Propane
Qty. D.M.S.*
Part
Number
Qty. D.M.S.*
Part
Number
ADG-78 II
204,000
4
#29
140820
4
#47
1408
05
881655
Shaded area is stated in metric equivalent
* D.M.S. (Drill Material Size) equivalents are as follows:
Natural Gas ............... #29 = .1360"
Liquid Propane Gas .. #47 = .0785"
