6
Gas
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION
A. SPECIFICATIONS
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
BASKET (
TUMBLER
) DIAMETER 44-1/2" 113 cm
BASKET (
TUMBLER
) DEPTH 24-7/8" 63.2 cm
BASKET (
TUMBLER
) MOTOR 1 HP* .746 kw
DOOR OPENING (D
IAMETER
) 31-3/8" 79.7 cm
BASKET (
TUMBLER
) VOLUME 22.4 cu. ft. .634 cu.m.
DRYERS PER 20'/40' CONTAINER 10/20
DRYERS PER 45'/48' TRUCK 24/24
VOLTAGE AVAILABLE 120-460v / 1ш-3ш / 3, 4w / 50/50 Hz
APPROX. WEIGHT (
UNCRATED
) 895 lbs. 406 kg
APPROX. WEIGHT (
CRATED
) 950 lbs. 431 kg
HEAT INPUT 204,000 btu/hr 51,408 kcal/hr
AIRFLOW 1,200 cfm 33.98 cmm
INLET PIPE SIZE** 3/4" 1.91 cm
Shaded areas are stated in metric equivalents
* For Non-Reversing Models.
** A minimum of 3/4"must be supplied to the gas inlet for each dryer.
