Adjusting Bass/Treble/Balance (Between
Left and Right)/Fader (Between Front
and Rear)/Defeat
1
Press MODE repeatedly to choose the desired
mode.
Each press changes the modes as follows:
BASS TREBLE SUBW* BALANCE FADER
DEFEAT VOLUME BASS
Bass Level: –7 ~ +10
Treble Level: –7 ~ +7
Subwoofer : 0 ~ +15
Balance : L15 ~ R15
Fader : R15 ~ F15
Defeat : ON/OFF
Volume : 0 ~ 35
• If MODE is not pressed within 5 seconds after selecting the BASS,
TREBLE, BALANCE, FADER, DEFEAT or SUBW mode, the unit
automatically returns to normal mode.
* When the subwoofer mode is set to OFF, its level cannot be adjusted.
2
Turn the Rotary encoder until the desired sound is
obtained in each mode.
By setting Defeat ON, previously adjusted settings of BASS
and TREBLE will return to the factory defaults.
• Depending on the connected devices, some functions and display
indications do not work.
Setting the Bass Control
You can change the Bass Frequency emphasis to create your own tonal
preference.
1
Press MENU to select the BASS ENGINE mode, then
press MODE.
BASS ENGINE SETUP RETURN (OFF) BASS ENGINE
2
Press or to select the BASS (bass Centre
frequency) control mode.
BASS TREBLE
3
-1 Press SOURCE/POWER to select the desired bass
centre frequency.
80Hz 100Hz 120Hz 60Hz 80Hz
Emphasizes the displayed bass frequency ranges.
3
-2 Press BAND to select the desired bass bandwidth.
Changes the boosted bass bandwidth to wide or narrow. A
wide setting will boost a wide range of frequencies above
and below the centre frequency. A narrower setting will
boost only frequencies near the centre frequency.
Sound Setting
BAND
Rotary
encoder
MODE
MENU
SOURCE/
POWER
Setting the Bass Centre Frequency
Setting the Bass Bandwidth
