S ON/OFF (Power) button and

Power/Charge lamp

T Mode dial
U Jog dial
V MENU button
W

/ (In-Camera Guide/Delete)

button

X Finder adjustment dial
Y Multi connector (Type3c)
Z Connector cover
wj HDMI connector
wk DC IN connector
wl RESET button
e; Speaker
ea LCD screen
es Battery/Memory card cover
ed Battery insertion slot
ef Battery eject lever
eg Access lamp
eh Memory card slot
ej Tripod receptacle

• Use a tripod with a screw less

than 5.5 mm (7/32 inches) long.
Otherwise, you cannot firmly
secure the camera, and damage to
the camera may occur.

(TransferJet™) mark
