Marking the Mounting Points
1.
Place the bottom portion of the wall plate to the reference line and mark the four (4) lag bolt mounting
points through the wall plate slots on the wall.
2.
Level the wall plate with the reference arrow pointing up to the ceiling (Figure 11).
16"
Figure 11. Marking the Mounting Points
Wall Plate
Mounting Slots
Level
Wood Studs
