PRODUCT DESCRIPTION
GENERAL OVERVIEW
1
2
4
2
3
3
1
2
3
4
5
5
5
2
3
1
1
Hob
2
Grill
3
Oven lamp
4
Fan and heating element
5
Shelf positions
COOKING SURFACE LAYOUT
4
6 7
1 3
5
2
1
Induction cooking zone 2300 W, with
the Power function 3200 W
2
Steam outlet
3
Induction cooking zone 2300 W, with
the Power function 3200 W
4
Induction cooking zone 2300 W, with
Power function 3200 W
5
Oven control panel
6
Hob control panel
7
Induction cooking zone 2300 W, with
the Power function 3200 W
ACCESSORIES
• Oven shelf
For cookware, cake tins, roasts.
• Deep roasting pan
To bake and roast or as a pan to collect
fat.
• Roasting pan grid
To put in the deep roasting pan.
