36 US
1
Confirm the measurement
result.
When the measurement ends, a beep
sounds and the measurement result
appears on the display.
2
Press AMP and then press V/v
repeatedly to select the item.
Then, press
.
3
Select “SAVE EXIT” in step 2 to
save the measurement result.
“COMPLETE” appears on the display
and the settings are registered as selected
position number.
4
Press V/v repeatedly to select
CAL TYPE, then press .
Tip
The size of a speaker (LARGE/SMALL) is
determined by the low frequency
characteristics.
The measurement results may vary, depending
on the position of the optimizer microphone
and speakers, and the shape of the room. It is
recommended that you follow the
measurement results. However, you can
change those settings in the SPEAKER menu
(page 51). Save the measurement results first,
then try to change the settings if you want.
Confirming/saving the
measurement results
Measurement
result Display Explanation
When the
measurement
process
completes
properly SAVE EXIT Proceed to step
2.
When the
measurement
process fails E -
xxx : xx
See “When
error codes
appear” (page
37).
Item Explanation
EXIT Exits the setting process
without saving the
measurement results.
LEVEL INFO Displays the measurement
result for speaker level.
DIST. INFO Displays the measurement
result for speaker distance.
PHASE INFO Displays the phase of each
speaker (in phase/out of
phase). See “When you
select “PHASE INFO””
(page 37).
WARN CHECK Displays warning
concerning the
measurement results. See
“When you select “WARN
CHECK”” (page 38).
SAVE EXIT Saves the measurement
results and exits the setting
process.
RETRY Performs the Auto
Calibration again.
Setting Explanation
FULL FLAT Makes the measurement of
frequency from each
speaker flat.
ENGINEER Sets the frequency
characteristics to a set that
matches that of the Sony
listening room standard.
FRONT REF Adjusts the characteristics
of all speakers to match the
characteristics of the front
speaker.
OFF Sets the Auto Calibration
equalizer level to off.
