VAIO Computer Reference Manual 44
PCI Riser Slot connector *
Pin Side B Signal Side A Signal
1 -12V TRST#
2 TCK +12V
3 GND TMS
4 TDO TDI
5 +5V +5V
6 +5V INTA#
7 INTB# INTC#
8 INTD# +5V
9 PRSNT1# Reserved
10 Reserved +5V (I/O)
11 PRSNT2# Reserved
12 GND GND
13 GND GND
14 Reserved *CLK2
15 GND RST#
16 CLK1 +5V (I/O)
17 GND *GND1#
18 *REQ1# GND
19 +5V (I/O) Reserved
20 AD31 AD30
21 AD29 *GNT2#
22 GND AD28
23 AD27 AD26
24 AD25 GND
25 *REQ2# AD24
26 C/BE3# ADSEL
27 AD23 +3.3V
28 GND AD22
29 AD21 AD20
30 AD19 GND
31 +3.3V AD18
32 AD17 AD16
33 C/BE2# +3.3V
34 GND FRAME#
