Sony KDL-32BX300 User Manual
Page 48
48
FOR SU-WL100
Step 1: Checking the parts required for the installation
Open the Wall-Mount Bracket package and check the contents for all required parts along with the
Instructions.
Step 2: Adjusting the position of the holders of the Base Plate
Refer to the Instructions for SU-WL100.
Step 3: Deciding on the installation location
Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL100.
Dimension Table
Figures in the above table may differ slightly depending on the installation.
CAUTION
The wall that the TV will be installed on should be capable of supporting a weight of at least four
times that of the TV.
Step 4: Installing the Base Plate on the wall
Refer to the Instructions for SU-WL100.
Unit: mm
(inches)
TV
Dimensions
Screen
center
dimensions
Length for each mounting angle
Weight
Angle (0°)
Angle (20°)
TV Model
A
B
C
D
E
F
G
H
TV
×4
KDL-22BX300
575
(22
3
/4
)
361
(14
1
/4
)
132.4
(5
1
/4
)
324
(12
7
/8
)
142
(5
5
/8
)
222
(8
3
/4
)
342
(13
1
/2
)
325
(12
7
/8
)
5.7 kg
(12.6 lb.)
22.8 kg
(50.4 lb.)
Screen center point
