Sony KDL-32BX300 - Manual (Page 11)

11
G
e
tting
Started
Shown with Component Connection
AUDIO
1
2
IN
AUDIO
OUT
(FIX)
AUDIO
SERVICE
ONLY
R L
AUDIO RGB
PC IN PC/HDMI 1
AUDIO IN
2
1
AUDIO
R L
R L
COMPONENT IN
P R P B Y
VIDEO IN
(MONO)
(1080p/1080i/
720p/480p/480i)
CABLE/
ANTENNA
DIGITAL
AUDIO OUT
(OPTICAL)
Rear of TV
CATV/Satellite antenna cable
Component video cable
Audio cable
HD cable box/
HD satellite box
AUDIO-R (red)
AUDIO-L (white)
P
R
(red)
P
B
(blue)
Y (green)
• If your equipment has a DVI output and not an HDMI output, connect the DVI output to the
HDMI IN 1 (with DVI-to-HDMI cable or adapter) and connect the audio output to the AUDIO
IN of PC IN. For details, see page 8.
