Sony KDL-32BX300 User Manual
Page 44
44
CAUTION
The wall that the TV will be installed on should be capable of supporting a weight of at least four
times that of the TV.
FOR SU-WL500
Step 1: Checking the parts required for the installation
Open the Wall-Mount Bracket package and check the contents for all required parts along with the
Instructions.
Step 2: Deciding on the installation location
Decide where you want to install your TV. Refer to the TV installation dimensions table.
Refer to the Instructions for SU-WL500.
Dimension Table
Figures in the above table may differ slightly depending on the installation.
Unit: mm
(inches)
TV
Dimensions
Screen
center
dimensions
Length for each mounting angle
Weight
Angle (0°)
Angle (20°)
TV Model
A
B
C
D
E
F
G
H
TV
×4
KDL-32BX300
804
(31
3
/4
)
497
(19
5
/8
)
172
(6
7
/8
)
426
(16
7
/8
)
156
(6
1
/4
)
303
(12)
479
(18
7
/8
)
460
(18
1
/8
)
9.1 kg
(20.1 lb.)
36.4 kg
(80.4 lb.)
Screen center point
