VAIO 505 SuperSlim Notebook User Guide
$
Back
Left
* Available on model PCG-505FX only.
Battery connector (page 9)
Plastic pen compartment (page 22)
DC In connector (page 8)
Phone line jack (page 34)
i.LINK (IEEE1394) (page 48)
*
Port replicator connector (page 35)
USB connector (page 49)
Floppy disk drive connector (page 24)
Line In connector (page 45)
External speaker connectors (page 46)
Headphone connector (page 47)
$
%
!
&
"
'
#
