VAIO MX Computer QuickStart
14
4 Using the same speaker wire, insert the other lead into the upper left-side
speaker terminal. Release the red tab and gently pull on the wire to set the
lead firmly.
5 Repeat the above steps to connect the left speaker to the computer.
To connect the speaker cables to the speakers
1 Press and hold the left, black tab on the back of the speaker. Insert the
black-line lead of the speaker wire into the terminal. Release the black tab
and gently pull on the wire to set the lead firmly.
2 Press and hold the right, red tab on the back of the speaker. Insert the
other lead of the same speaker wire into the terminal. Release the red tab and
gently pull on the wire to set the lead firmly.
3 Repeat the above steps to connect the second speaker wire to the other
speaker.
Connecting the speaker cable to the speakers
Black-line
color coding
