Sony MFM-HT205 User Manual
Page 32
32
Note
The inputs for main/sub pictures must be selected as shown below.
To change the sub picture’s size (PIP function: On)
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M/m buttons to select
(Option) and
press the OK button.
The “Option” menu appears on the screen.
3
Press the
M/m buttons to select “PIP/PAP” and
press the OK button.
4
Press the
M/m buttons to select “PIP/PAP Setting”
and press the OK button.
The “PIP/PAP Setting” menu appears on the screen.
5
Press the
M/m buttons to select “PIP On” and press
the OK button.
6
Press the
M/m buttons to select “PIP Size” and
press the OK button.
The “PIP Size” menu appears on the screen.
7
Press the
M/m buttons to select the desired size and
press the OK button.
• Large
• Middle
• Small
To change the sub picture’s position (PIP function: On)
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M/m buttons to select
(Option) and
press the OK button.
The “Option” menu appears on the screen.
3
Press the
M/m buttons to select “PIP/PAP” and
press the OK button.
4
Press the
M/m buttons to select “PIP/PAP Setting”
and press the OK button.
The “PIP/PAP Setting” menu appears on the screen.
5
Press the
M/m buttons to select “PIP On” and press
the OK button.
6
Press the
M/m buttons to select “PIP Position” and
press the OK button.
The “PIP Position” menu appears on the screen.
7
Press the
M/m buttons to select the desired position
and press the OK button.
You can choose one of 4 positions for the sub picture.
To select the audio input source (PIP function: On/PAP
function: On)
1
Press the MENU button.
The main menu appears on the screen.
2
Press the
M/m buttons to select
(Option) and
press the OK button.
The “Option” menu appears on the screen.
3
Press the
M/m buttons to select “PIP/PAP” and
press the OK button.
4
Press the
M/m buttons to select “PIP/PAP Setting”
and press the OK button.
The “PIP/PAP Setting” menu appears on the screen.
5
Press the
M/m buttons to select “PIP On” or “PAP
On” and press the OK button.
6
Press the
M/m buttons to select “Audio Select” and
press the OK button.
The “Audio Select” menu appears on the screen.
7
Press the
M/m buttons to select the desired source
and press the OK button.
• Main: The sound from the input source selected for the
main picture will be used.
• Sub:
The sound from the input source selected for the
sub picture will be used.
Tip
If you select “Sub,” is displayed in the screen.
Main
Sub
PC 1
PC 2
TV
COMPONENT
VIDEO 1
VIDEO 2
Option
1680
× 1050/60 Hz
Set
Exit
MENU
Select
OK
PIP/PAP
PIP/PAP Setting :
PIP On
PIP/PAP :
TV
PIP Size :
Large
PIP Position
Middle
Audio Select :
Small
DVI-D: PC 1
Option
1680
× 1050/60 Hz
Set
Exit
MENU
Select
OK
PIP/PAP
PIP/PAP Setting :
PIP On
PIP/PAP :
TV
PIP Size :
Large
PIP Position
Audio Select :
DVI-D: PC 1
