Construction of the appliance
12
Construction of the appliance
Front view
Operator control mask
Condensate container
with handle flap
Ventilation
slots
Base mask
in front of heat
exchanger
Fluff filter
Fill-in door
(stop exchangeable)
Type plate
Feet
(all height-adjustable)
Filament lamp
bulb
for
interior
illumination
(inside the
drum)
