Nilfi sk ALTO Operator’s Manual - SCRUBTEC R Manual Steering Form No. 71274A Page -7-
Display Screens For Scrubtec R
Traverse speed indicator
1 = low 0-3 KPH
2 = med 0-5 KPH
3 = high 0-6.4 KPH
Position arrow indicating current position
of squeegee (up or down)
Indicators are on,
showing current set-
tings.
Screens
Available
to Operator
“Battery” blinks when
low voltage occurs.
Water “droplets” off when solution is off and
they are fl ashing when solution is on.
Arrows indicating vacuum sta-
tus. They are fl ashing when vac
is on and off when vac is off.
SCREEN 1
SCREEN 2
Example
SCREEN 3 (Diagnostic)
The Diagnostic only. It will not show unless a fault with
the machine occurs. When the fault happens the icon
and error code will be displayed.
