Page -16- Form No. 71274A Nilfi sk ALTO Operator’s Manual - SCRUBTEC R Manual Steering
Figure 19
Figure 20
How To Operate The Machine
How to Return One Touch to Factory Default Settings
To restore the factory settings, follow the procedures below:
1. Press and hold the green one touch button (fi gure 17) until you hear
a double beep from the machine. NOTE: The time required for
this will be approximately 15 seconds.
2. The settings should be returned to 2 bars of solution and 1 bar of
brush pressure. NOTE: The squeegee vac switch must be in the
middle position for default settings to work.
How to Move the Machine Without Power (see fi gure 18)
1. Engage manual override on brake (see page 9, “Parking Brake”).
2. Remove foot plate and 4 screws and locate steering motor.
3. Using the knob on steering motor, turn shaft on motor in direction
you wish to turn machine.
4. Slowly push machine to desired location. NOTE: If you attempt to
push machine too fast it will limit top speed. If this happens,
stop and restart.
5. After moving machine, disengage manual brake override. NOTE:
Machine will not function if override is engaged.
Seat Adjustment (Standard)
The standard seat is not adjustable forward or backward.
Seat Adjustment (Deluxe)
The optional deluxe seat is adjustable in three ways:
1. The seat can be adjusted to the forward/backward position by using
the lever on the lower right side of the seat . Moving the lever will
allow the seat to slide into the preferred position. See fi gure 19.
2. To adjust the angle of the back support portion of the seat, turn the
lever located in the middle right position of the seat. Turning this
clockwise will make the seat more vertical. Turning the knob coun-
terclockwise will tilt the seat back.
See fi gure 20 A.
3. To adjust the suspension of the seat for operator comfort, use the
lever on the side of the back support section of the seat. This has
three positions. The upper position is for light weight operators. The
middle position is for medium weight operators. The bottom position
is for heavy weight operators. See fi gure 20, B. NOTE: The lever
must be pressed fi rmly to change positions.
Figure 17
Figure 18
